Home > Products > pricision alloy > Square Steel Flat Bar
Square Steel Flat Bar
- 1500 Ton / Tons per Month
- Shanghai
- T/T D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | longxin-alloy | |
| Model Number | 010 | Application | Movie machine, Checking attendance machine.iron core for Transformer, | |
| Shape | flat bar | Material | Ni-Cr-Fe | |
| Dimensions | according to clients' requirement | Chemical Composition | Ni-Cr-Fe |
Product Description
Specifications
Square Steel Flat Bar1. ISO9001 certification;
2.fine after-sale services;
3.small order accepted;
4.samples available;
Square Steel Flat Bar
Precision alloy
Brand(label):
1.Soft magnetic alloy:
high permeability alloy:1J79,1J85,1J86,1J116,1J117,1J36
High permeability and saturation induction alloy:1J50,1J46,1J54
Compensator alloy:1J38.1J30,1J31,1J32
High hardness,high resisitance,high magnetic conductibility alloy:1J87,1J89,1J88
Magnetic head material:1J75,1J77C,1J79C,1J85C,1J87C,1J92,1J93,1J94,1J95
Property:magnetic property, high magnetic conductibility,high resisitance,
High hardness,high saturation induction,ect.
Function:memory element,compensating element,inductance element for
Transformer, magnetic amplifier.isolating flake,magentic head for
recorder, Movie machine, Checking attendance machine.iron core for Transformer,choke,pulse transformer,relay,and magnetic amplifier.
2.Expanding alloy
fernico glass sealing alloy:4J29,4J44,4J49
fernico sealing alloy:4J33,4J34,4J32
Iron-nickel glass sealing alloy: 4J42,4J30
Iron-nickel-chromiun glass sealing alloy:4J6
Iron-chromiun glass sealing alloy:4J28
Low-expandsion alloy:4J36
Other:4J50,4J58
Property:dense oxide film,strong anti-oxidability,good plasticity,
low expansion coefficient,abradability.
Function:fusion bonding,welding,machining,sealing.
Specs:thickness 0.08mm~3mm width 5mm~250mm
| Grade | C | S | P | Mn | Si | Ni | Cr | Co | Mo | Cu | Al | Nb | Fe | other |
| 1J30 | max0.04 | max0.02 | max0.02 | max0.4 | max0.3 | 29.5~30.5 | balance | |||||||
| 1J31 | max0.04 | max0.02 | max0.02 | max0.4 | max0.3 | 30.5~31.5 | balance | |||||||
| 1J32 | max0.04 | max0.02 | max0.02 | max0.4 | max0.3 | 31.5~32.5 | balance | |||||||
| 1J36 | max0.03 | max0.02 | max0.02 | max0.6 | max0.2 | 35.0~37.0 | balance | |||||||
| 1J38 | max0.05 | max0.02 | max0.02 | 0.3~0.6 | 0.15~0.3 | 37.5~38.5 | 12.5~13.5 | balance | ||||||
| 1J50 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | 0.15~0.3 | 49.0~50.5 | max0.2 | balance | ||||||
| 1J46 | max0.03 | max0.02 | max0.02 | 0.6~1.1 | 0.15~0.3 | 49.0~50.5 | max0.2 | balance | ||||||
| 1J54 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | 1.1~1.4 | 49.5~51.0 | 3.8~4.2 | max0.2 | balance | |||||
| 1J79 | max0.03 | max0.02 | max0.02 | 0.6~1.1 | 0.3~0.5 | 78.5~80.0 | 3.8~4.1 | max0.2 | balance | |||||
| 1J85 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | 0.15~0.3 | 79.0~81.0 | 4.8~5.2 | max0.2 | balance | |||||
| 1J86 | max0.03 | max0.02 | max0.02 | max1.0 | max0.3 | 80.5~81.5 | 5.8~6.2 | balance | ||||||
| 1J87 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | max0.3 | 78.5~80.5 | 1.6~2.2 | 6.5~7.5 | balance | |||||
| 1J88 | max0.03 | max0.02 | max0.02 | max0.6 | max0.3 | 79.5~80.5 | 7.5~9.0 | balance | ||||||
| 1J89 | max0.03 | max0.02 | max0.02 | 0.5~1.0 | max0.3 | 78.5~80.5 | 3.5~4.5 | 3.0~3.6 | balance | Ti:1.8~2.8 | ||||
| 1J116 | max0.03 | max0.02 | max0.02 | max0.6 | max0.2 | 15.5~16.5 | balance | |||||||
| 1J117 | max0.03 | max0.02 | max0.02 | 0.3~0.7 | max0.15 | 0.50~0.70 | 17.0~18.5 | balance | Ti:0.3~0.7 | |||||
| 4J06 | max0.05 | max0.02 | max0.02 | max0.25 | max0.3 | 41.5~42.5 | 5.5~6.3 | max0.2 | balance | |||||
| 4J28 | max0.12 | max0.02 | max0.02 | max1.00 | max0.7 | max0.5 | 27.0~29.0 | balance | N:max0.2 | |||||
| 4J29 | max0.03 | max0.02 | max0.02 | max0.5 | max0.3 | 28.5~29.5 | max0.2 | 16.8~17.8 | max0.2 | max0.2 | balance | |||
| 4J33 | max0.05 | max0.02 | max0.02 | max0.5 | max0.3 | 32.1~33.6 | 14.0~15.2 | balance | ||||||
| 4J34 | max0.05 | max0.02 | max0.02 | max0.5 | max0.3 | 28.5~29.5 | 19.5~20.5 | balance | ||||||
| 4J36 | max0.05 | max0.02 | max0.02 | 0.2~0.6 | max0.3 | 35.0~37.0 | balance | |||||||
| 4J32 | max0.05 | max0.02 | max0.02 | 0.2~0.6 | max0.2 | 31.5~33.0 | 3.2~4.2 | 0.4~0.8 | balance | |||||
| 4J42 | max0.05 | max0.02 | max0.02 | max0.8 | max0.3 | 41.5~42.5 | max0.1 | max0.1 | balance | |||||
| 4J44 | max0.3 | max0.02 | max0.02 | max0.5 | max0.3 | 34.2~35.2 | max0.2 | 8.5~9.5 | max0.2 | max0.2 | balance | |||
| 4J49 | max0.05 | max0.02 | max0.02 | max0.4 | max0.3 | 46.0~48.0 | 5.0~6.0 | balance | B:max0.02 | |||||
| 4J50 | max0.05 | max0.02 | max0.02 | max0.8 | max0.3 | 49.5~50.5 | max0.1 | balance | ||||||
| 4J58 | max0.03 | max0.015 | max0.6 | max0.25 | 57.5~59.5 | balance | ||||||||
| 1J75 | max0.03 | max0.02 | max0.02 | 0.5~1.0 | max0.3 | 74.0~76.0 | 1.5~2.0 | 5.0~7.0 | balance | W:1.0~1.5 | ||||
| 1J77C | max0.03 | max0.02 | max0.02 | max0.7 | max0.3 | 76.5~78.0 | 3.5~4.5 | 3.8~5.3 | balance | |||||
| 1J79C | max0.03 | max0.02 | max0.02 | 0.7~1.2 | 0.3~0.6 | 78.0~81.5 | 3.7~4.5 | balance | ||||||
| 1J85C | max0.03 | max0.02 | max0.02 | 0.3~0.7 | 0.15~0.30 | 80.0~81.5 | 5.0~6.0 | balance | ||||||
| 1J87C | max0.03 | max0.02 | max0.02 | 0.3~0.6 | max0.3 | 80.0~81.5 | 1.0~2.0 | 4.0~5.5 | balance | |||||
| 1J92 | max0.03 | max0.02 | max0.02 | max0.6 | max0.3 | 80.1~81.1 | 1.0~1.5 | 3.0~4.0 | balance | W:1.0~1.5 | ||||
| 1J93 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | max0.3 | 80.5~81.5 | 3.0~4.0 | 3.0~4.5 | balance | |||||
| 1J94 | max0.03 | max0.02 | max0.02 | 0.3~0.6 | max0.3 | 79.5~81.0 | 0.3~0.7 | 4.5~5.0 | 1.5~2.5 | 0.6~1.0 | balance | |||
| 1J95 | max0.03 | max0.02 | max0.02 | 2.8~3.3 | 83.0~84.0 | 1.2~1.6 |
Specification: Plate, sheet, strip, rod, bar, wire, tube
We are looking forward to cooperating with you!
