Spark High Quality LED Tunnel Light 60W
Negotiable
/ Piece
2 Pieces(Min. Order)
- Shenzhen
- T/T
You May Like
Product Details
| LED Light Source | CREE/Lumileds | Input Voltage(V) | 100-277VAC | |
| Lamp Power(W) | 60 | Lamp Luminous Flux(lm) | 5700 | |
| Lamp Luminous Efficiency(lm/w) | 95 | Working Temperature(℃) | -40, 80 | |
| Working Lifetime(Hour) | 50000 | Lamp Body Material | Aluminum Alloy | |
| IP Rating | IP65 | Certification | CE, CQC, FCC, PSE, UL, VDE | |
| Place of Origin | Guangdong, China | Brand Name | Spark LED Tunnel Light | |
| Model Number | SPT-D60 |
Product Description
Spark High Quality LED Tunnel Light 60W
Product Description:
1. Die casting aluminum alloy lamp housing with excellent heat dissipation; clear parts are high strength toughened glass; with a good performance of dust resistance, water resistance, and shock resistance.
2. Unique optical design & rectangular beam; every single LED matched with a reflection cup, which will properly control the light distribution, and ensure illumination and uniformity of light, meanwhile, eliminate LED glare.
3. Lamp and power driver are independently assembled with high overall reliability and convenient for maintenance.
Main Technology Index:
| Model No. | SPT-D60 | |
| LED Light Source | CREE/Lumileds | |
| LED Quantity | 24 x 1 PCS LED | |
| LED Luminous Efficiency | 217 lm/700mA Cool white | |
| Lamp Rated Total Power | 60W ± 10% | |
| Lamp Rated Luminous Efficiency | 95 lm/w | |
| LED Driver Current | 700mA | |
| Lamp Rated Total Luminous Flux | 5700 lm ± 10% | |
| Average lllumination and Effective Area | 3M Height | 6m×7m ≥244LUX |
| 4M Height | 8m×9.5m ≥137LUX | |
| 5M Height | 10m×12m ≥88LUX | |
| 6M Height | 12m×14m ≥61LUX | |
| Color Rendering Index(CRI) | Ra>70 | |
| Power Efficiency | 90% | |
| Color Temperature(Color Temperture) | Cool white: 5000-5700K Pure white: 4000-4500K Warm white: 3000-3500K | |
| Beam Angle | 100°X90° | |
| Input Voltage | 100-277VAC | |
| Frequency Range | 47-63Hz | |
| IP Rating | IP65 | |
| Power Factor(PF) | ≥ 0.95 | |
| Total Harmonic Distortion(THD) | < 15% | |
| Storage Temperature | -40°C--+80°C | |
| Working Temperature | -40°C--+50°C ; 10%-90%RH | |
| Junction Temperature(Tj) | 85°C± 10%(Ta+25°C) | |
| Light Body Material | Aluminum Alloy | |
| Working Lifetime | > 50,000hrs | |
| Product Dimension(mm) | 240(L) x 295(W) x 213(H) (mm) | |
| Package Size(mm) | 310(L) x 365(W) x 231(H) (1 PC) | |
