High Quality Fine Fog Misting System

Specifications

(High pressure Nozzles)(Brass Fog Nozzles)

High Pressure Fine Misting System, Low Pressure Misting System:

  1. Nozzle Material: Brass, SS

  2. Orifice:Ruby,Ceramic,SS

  3.Connection Type: Quick Slip Lock, Thread type

  3.Tube size: 3/8" (9.52mm)

  3. Working Pressue: 9bar to 100bar (100PSI to 1000PSI)

  4. Droplet size: 5-40 Micron

  5. Motor Model: 220V/50HZ, 220V/60HZ, 380/50HZ

  6. Fittings Models: Nozzle, Nozzle connector, Tubing, Tubing Cutter, Water filter, Tee, Elbow, End, End Plug, Union, Male/female adapter, ball valve and water filter, etc.

Ideal Spray Professional make high quality misting system kits for cooling and misting, DIY mist cooling system simple for any applications.

We also separately supply the Fog misting nozzle, connectors, coupling, tubing and pumps.

1. Fog Misting Nozzle:

    Orifice diameter: 0.1mm up to 0.5mm

    Working pressure: 6-70 bar

    Body material: 304SS, brass and 316ss

    orifice material: SS, ceramic and ruby

    Inlet thread: 10/24, 12/24, 3/16 and 1/8

2. 3/8 Connectors,Fittings and Couplings:

    Material: brass and SS

    Nozzle thread: 10/24,12/24UNC

    Tubing Size: 3/8" (9.52mm)

     Working Pressure: 70bar/1000PSI

3. Nylon Tubing & PE Tubing:

    Outside diameter: 3/8"

    Working Presure: 70 bar up to 120 bar

    Temperature:40C.degree

4. Misting Pump Capacity:

    0.3LPM, 1LPM, 2LPM,3LPM,5LPM,6LPM,7LPM,9LPM,11LPM,12LPM,15LPM,17LPM,18LPM,21LPM,25LPM

5. Pump Specification:

Pump No. : HP

Pump : Plunger

Flow rate: 3.0L/min

Pressure: 60-80bar

Power: 800w

Rpm: 1400rpm

110 / 220 Volt - 50 / 60 HZ

6.Technical data sheet for Fog Nozzles:

(1/8'' SS316 Fog nozzle) (Low Pressure Fog Nozzle)

We make complete fog/mist cooling system, e.g.: Fog Machine/Pump, High Pressure Pipe/Tubing, Thread Connetors and Slip Lock Fittings, Fog/mist Nozzles,water filter and all related Accessories.

Please call us or email to us, we will reply you soon!

Tel: +86 0755 81099407

E-mail address: sales at

 7.Photo of High Pressure Misting Systems:
