Home > Products > Mixing Machine > PET Crystallizer/Plastic Dry Machine
PET Crystallizer/Plastic Dry Machine
- shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | Friend Machiery | Model Number | PET Crystallizer, PET series | |
| Warranty | one year |
Product Description
Specifications
1.can improve drying efficiency and production2.crystallization dryer;plastic dewatering machinery
3.Lower price.
Performance and features:
PET Hopper Plastic Dryermainly used for PET pre-crystallization and hollow agitation to maintain a small slice of the relative motion, in order to prevent node biopsy guitar, for the post, create favorable conditions for high-temperature drying. It is through the materials, along the heat exchange, and continuously removes moisture. Remove a significant portion of the surface of adsorbing water, slicing a 35 percent degree of crystalline, and then the wind from the pre-crystallization from the top to complete the pre-high-efficiency crystalline drying process.
Model | PET315 | PET400 | PET500 | PET 800 | PET1250 | PET 1600 | PET5000 |
Useful volume (L) | 315L | 400L | 500L | 800L | 1250L | 1600L | 5000L |
Charging capacity (kg) | 230kg | 300kg | 375kg | 600kg | 900kg | 1200kg | 3750kg |
Heating power (kw) | 12kw | 15kw | 18 kw | 24 kw | 36 kw | 42 kw | 63 kw |
Fan power (kw) | 0.37 kw | 0.55 kw | 0.55 kw | 1.1kw | 1.1 kw | 2.2kw | 5.5 kw |
Mixing power (kw) | kw | 1.1 kw | 0.75 kw | 0.75kw | 1.1 kw | 1.1kw | 3 kw |
Mixing speed (r/min) | 9.1 | 9.1 | 3.75 | 3.75 | 3 | 3 | 2.87 |
Heat Isolation (mm) | 40mm thickness | ||||||
Heating temperature (°C) | 120—130°C | ||||||
Crystallizing time (h) | 1—1.5hour | ||||||
Power supply | AC380V 50Hz Three-phase four-wire (Chinese standard) | ||||||
FOB CHINA Price (/set) | |||||||
