Home > Products > Steel Wire > Spring Steel Wire
Spring Steel Wire
- NANTONG or SHANGHAI
- T/T
You May Like
Product Details
| Steel Grade | 60# 65# 70# 72# 80# | Standard | AISI, BS, GB, JIS | |
| Wire Gauge | 0.2-13mm | Place of Origin | Jiangsu, China | |
| Type | Spring | Application | Other, Steel Wire Rope | |
| Alloy Or Not | Non-alloy | Special Use | Cold Heading Steel | |
| Model Number | 0.2-13mm | Brand Name | Jintu |
Product Description
1.Diameter range:0.2-13mm
2.Main application:making spring,mattress,wire rope.
3.Standard:GB4357,DIN17223,JIS G 3521
High Carbon Spring Steel Wire Performance:
1.Diameter range:0.2-13mm
2.Main application:making spring,mattress,wire rope.
3.Standard:GB4357,DIN17223,JIS G 3521
Standard:DIN17223:
High Carbon Spring Steel Wire | |||
wire diameter(mm) | Tensile Strength(N/mm² ) | ||
Grade A | Grade B | Grade C | |
0.30 | 2370-2650 |
| |
0.40 | 2270-2550 |
| |
0.50 | 2200-2470 |
| |
0.60 | 2140-2400 |
| |
0.70 | 2090-2350 |
| |
0.80 | 2050-2300 |
| |
1.00 | 1720-1970 | 1980-2220 |
|
1.20 | 1670-1910 | 1920-2160 |
|
1.40 | 1620-1860 | 1870-2100 |
|
1.60 | 1590-1820 | 1830-2050 |
|
1.80 | 1500-1780 | 1790-2010 |
|
2.00 | 1520-1750 | 1760-1970 | 1980-2200 |
3.00 | 1410-1620 | 1630-1830 | 1840-2040 |
4.00 | 1320-1520 | 1530-1730 | 1740-1930 |
5.00 | 1260-1450 | 1460-1650 | 1660-1840 |
6.00 | 1210-1390 | 1400-1580 | 1590-1770 |
7.00 | 1160-1340 | 1350-1530 | 1540-1710 |
8.00 | 1120-1300 | 1310-1480 | 1490-1660 |
9.00 | 1090-1260 | 1270-1440 | 1450-1610 |
10.00 | 1060-1230 | 1240-1400 | 1410-1570 |
11.00 |
| 1210-1370 | 1380-1530 |
12.00 |
| 1180-1340 | 1350-1500 |
13.00 |
| 1160-1310 | 1320-1470 |
ISO9001:2008:
Factory Tour:
Loading Capacity:
20" container:20-25 Ton.
Contact Us
- Nantong Huaxing Steel Wire Products Co., Ltd.
- Contact nameYing Zhu Chat Now
- Phone86-513-85916090
- AddressNo.131, Ruixing Road, Zhuhang Town, Nantong, Jiangsu
