Goat Antilope Agneau Slaughter
US$ 15,500 - 65,700
/ Set
1 Set(Min. Order)
- Qingdao
You May Like
-
Sheep Goat Abattoir Equipment Automatic Bloodletting Line Bleeding Conveyor
-
Stainless Steel Sheep Skin Removal Machine
-
Stainless Steel Sheep Hide Removing Machine
-
Stainless Steel Sheep Hide Skinning Machine
-
Stainless Steel Sheep Skin Machine to Pull Sheep Hide
-
Automatic Mutton Meat Processing Plant in Mutton Slaughterhouse
Product Details
| Condition | New | Application | Cattle | |
| Place of Origin | Shandong, China | Brand Name | ONESTOP | |
| Model Number | N/M | Voltage | 380V/220V | |
| Power(W) | 5.5kw | Dimension(L*W*H) | 1800*1650*1200mm | |
| Weight | 1500kg | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
| 1000~1500sheep/day Slaughter and Parting Equipment List | ||||||
| No | Name | Model | Unit | Qty | Remarks | |
| 1. Sheep Slaughter part | ||||||
| 1 | Sheep Auto Blooding Line | YFX-100 | M | 50 | Including: track, carriages, chain lifting curved track, up and down slopes and connectors. Are hot-galvanized structure. Sheep hanging space: 1200mm. | |
| 2 | Drive device | Set | 2 | Rack is hot galvanized structure,Electromagnetic stepless speed regulation | ||
| 3 | Tensioner device | Set | 2 | Rack is hot galvanized structure, Screw tightening | ||
| 4 | Rotary device | Set | 4 | Rack is hot galvanized structure. | ||
| 5 | Sheep shackle chain | YTL-500 | Pcs | 40 | Made by SUS | |
| 10 | Cleaning device for plates and Hooks | Set | 1 | Made by stainless steel | ||
| 11 | White Viscera chute | NC-1 | Set | 1 | Made by stainless steel | |
| 12 | Red Viscera chute | NC-1 | Set | 1 | Made by stainless steel | |
| 13 | Sheep Double hook &double pulley | Dg65 | Pcs | 500 | Made by stainless steel | |
| 14 | Trimming and empty pulley back double rail hand push line | STX-164 | M | 120 | With hot dip galvanized track beam, hanger, rail and connecting pieces. | |
| 15 | Switch | R300 | Set | 6 | Hot dip galvanized with hanger. | |
| 16 | Curved Rail | R300*90. | Set | 10 | Hot galvanized | |
| 17 | Sheep Carcass Electric Scale | 300Kg | Set | 1 | With Screen and printing device | |
| 18 | Hand washing device with tool sterilizer | DJX-1 | Set | 8 | Stainless steel, tool sterilizer with plastic holder, overflow pipe, manual valve. Hand washing device with stainless steel anti-splash plate, anti-water pipe and the pedal valve. Does not include water supply and drainage pipe installation | |
| 19 | Apron Washer | Set | 4 | Apron cleaning for slaughter station, floor mounted. Including: stainless steel production, the foot switch, a water jet nozzle, not including water supply and drainage pipe installation | ||
| 20 | Manual Spraying Device | Pcs | 3 | Made by stainless steel | ||
| 21 | Electric Device Control Cabinet | Pcs | 3 | Used for bloodletting automatic line, hides conveyor, carcass automatic line and synchronous health inspection | ||
| 2. Rail for Acid Drainage and Dividing part | ||||||
| 1 | Double Rail Hand push Line | STX-164 | M | 230 | With hot dip galvanized track beam, hanger, rail and connecting pieces. | |
| 2 | Switch | R300 | Set | 32 | Hot dip galvanized with hanger. | |
| 3 | Curved Rail | R300×90. | Set | 6 | Hot dip galvanized. | |
| 4 | Rail breaker | DGQ-1 | Set | 4 | Hot dip galvanized. | |
| 3. Deboning and Dividing Part | ||||||
| 1 | Single layer dividing conveyor | Set | 2 | The frame, supporting roller are made of stainless steel, the conveying belt is a white food standards with, band width 500mm; captain: 12000mm; machine power: 1.1kw | ||
| 2 | Dividing table | Set | 32 | Table size:1200*700*800mm,stainless steel frame, top surface by plastic anti-slide plate | ||
| 3 | Packing table | Set | 6 | All by stainless steel, table size: L1800×W900×H800mm | ||
| 4 | Standard Cart | 200L | Set | 6 | Made by stainless steel | |
| 5 | Electric Control Cabinet | Pcs | 1 | For dividing conveyor | ||
| 4. Installation materials (main beam process, suspended material): Total 16T,$1160/m fob,hot dip galvanized. | ||||||
| 5. Installation cost: Machine Supplier needs to arrange workers to guide for machine and equipment installation and Debugging, Buyer should take the charge of round tickets, salary, accommodation. This cost is about 5% of equipment. Buyer also can pay separately for it. | ||||||
| 6. Transportation cost to the port: to be discussed | ||||||
