2016 Real Time Professional Car Gps Tracker Supplier With High Quality Mini Gps Tracking Device

2016 real time  Professional car gps tracker supplier with high quality mini gps tracking device

1.ACC detection

2.Remote engine
3.Can be use for car,motorcycle
4.GPRS/GSM/TCP/UDP protocol

5. Acceleration sensor trigger vibration alert

6.Waterproof

7.FOTA

8.LBS tracking GSM ID

9.Rel time racking

10.TF card stores the data

GPS motorcycle tracker,XT-009 GPS / GSM tracking device is a built-in GPS and GSM / GPRS module remote location equipment for vehicles. It is  a small, precision
high, remote location tracking device. Based on the Global Positioning System satellites, under dynamic conditions it provides accurate positioning information,personal remote positioning
It transmits the longitude and latitude coordinate to authorized cell phone, sends data through the GPRS channel to the service platform for real-time tracking.detail information,

1.Waterproof IP67

2.Build in GSM/GSM antenna, as small as our TK102, easy to hide to motorcycle.

3. DC6~36V car/motorcycle battery supported

4.cellent for fixing the position even at a weak signal status.

5.Very Low power consumption, long time battery life (120hours )

6.Fast Signal Acquisition

7.Support single location and continuous tracking

8.Support speed alarm/movement alarm/low battery alarm

9.Can be set up 5 authorized mobile number

10.Support check location by SMS and Internet

11.Locate the position by mobile phone via SMS

12.SOS button send out exact location for immediate rescue/action.

13.SD card save gprs data

14.Build in Montion sensor. send shake alarm when someone touch tracker .

15.Main power cut/ lost alarm

16.Distance limited data transmition

17.Remote cut-off electricity &oil function

18.ACC start/ ACC off alert

GPS motorcycle tracker XT-009 specification,

Dimention:73*46*24(mm)

Weigh:50g
Network:GSM/GPRS
Band:850/900/1800/1900Mhz
GPS chip:SIRF3 chip
GPS sensitivity:-159dBm
GPS accuracy:5-10m
Start-up time:Cold status 45s
                    Warm status 35s
                    Hot status 1s
External power supply:DC6-36V input
Battery:3.7V 1000mAh battery
Standby:120hous
Storage Temp:-40°C to +85°C
Operation Temp:-30°C to +80°C
Humidity:5%--95% non-condensing

GPS motorcycle tracker XT-009 application,

Manage motorcycle /vehicle rental or outside equipment,etc,

Fleet management,

Covert Tracking

GPS tracker motorcycle XT-009 hardware and Accessories

GPS tracker motorcycle XT-009  package Contents,

1 x GPS/GSM Vehicle Tracker
1 x Lithium battery
1 x Cable  (Used for connecting the GSM/GPS tracker to motorcycle or car)
1 x Instruction on CD-ROM

1 x relay to remote engine or open the door

1x gift box

Please have deep conception of GPS tracker motorcycle XT-009 again,check the outside and inside,

GPS tracker motorcycle XT-009  circuit diagram wire connection,

How to use the GPS tracker motorcyle XT-009 to find a target,we give youo 3 ways.

Track via  SMS on your smart phone which has a mapping system,GPS Tracker motorcycle gives you a google link,click the google link,the location is displayed in your phone,you get your target.

You have a simple phone,you don't want to use internet in your smart phone,you want see big photo of your target,use a phone with your PC.GPS motorcycle tracker gives you the coordinates,put the coorindates in google mapping,you can find the location in front of you.

You want to have a professional tracking life,you want to see different targets in one page,you need check a very short interval,use the PC tracking software,it is a website,put the username and password,you will see a single device,or you can check a whole team with more than 1pc simultaneously

Factory

Fair

Certification,

GPS tracker motorcycle has 2 versions, you can also use it as a portable tracker,please contact us back for more details.

We do have other vehicle devices with 3G version,we do have  other devices with SkyTraq+GLONASS Chipset,you are welcome to be contacted for more details.

Anyone has an order over 500pcs will be certainly obtained a open source tracking software kits which can be configured in your own PC server for OEM tracking.Or you can buy it with cheap cost,we promise the tracking software is one of the best one in tracking business range.
