Product Details

Place of Origin	Zhejiang, China	Brand Name	CY solar bracket
Model Number	solar bracket for flat roof	Type	Other, solar brackets
Application	Other, Solar panel module	Pipe Material	Other, Aluminum alloy

Product Description

Specifications

Solar bracket
1.Top-quality aluminum support for solar modules
2.Easy installation
3.Green product
4.Competitive price

Solar bracket for flat roof:

Solar brcket

solar brackets for flat roof:

This solar bracket is characterized by:
1. The angle can be adjusted easily.
2. Easy installation, the installation process without nuts, as long as the hex wrench and ordinary wrench to complete the installation. Installation time than the average reduction of 25% of similar products.
3. Solid and reliable quality can be adjusted according to the level of an apartment roof in order to guarantee the level of support.

4. This kind of solar bracket is of high quality with the approval of ROHS/CE/ISO.

Technical characteristics of solar bracket:

Item	Solar bracket for flat roof
Installation site	Flat roof
Installation angle	Based on customers’ requirements
Installation height	Based on customers’ requirements
Wind resistance	45m/s
Snow load	1.4KN/m²
Solar panel type	with or without frame
Components arrangement	horizontal or vertical
International criteria	eligible
Support track	aluminum alloy extrusion
Color	natural color
Quality warranty	10 years
Service life	25 years
