Home > Products > paper machine > high quality good selling 1600mm fluting paper making machinery
high quality good selling 1600mm fluting paper making machinery
- tianjin shanghai etc.
- T/T
You May Like
Product Details
| Condition | New | Type | Other, 1600mm fluting paper making machinery | |
| Place of Origin | Henan, China | Brand Name | huaxia | |
| Model Number | 1600mm | Certification | CE | |
| Warranty | one year |
Product Description
A. Main technical parameters:
- product varieties: cardboard paper, corrugated paper and so on.
- papermaking quantitative:180-350g/m2
- net paper width: 1600mm
- the working speed :40-90m / min
- capacity:28-35t/d
- driving: AC frequency sectional drive
- installed capacity: 149.5kw
- rail distance: 2400mm
- design standard: national standard export equipment
B. The summarize of the key components:
1. cylinder part: including cylinder mould, couch roller, running roller, suction felt box and sparge pipe.
2. press part: preload top and bottom roll, press top and bottom roll, blanket press top and bottom roll, running roller, expander roll, felt suction box sparge pipe, corrector, felt tightener, scraper, rack and working board.
3. drying part: including vat, running roller, spring paper carrying roll, corrector, manual tightener, scraper, rack and working board and so on.
4. drive part: AC frequency sectional drive
5. base part: 230 flange rail, 360 double-groove bottom rail, foundation bolt, wedge.
Contact Us
- Qinyang City Huaxia Paper Making Machinery Co., Ltd.
- Contact namekarl Lin Chat Now
- Phone86-0391-5659000
- AddressQinnan Industrial Area,Qinyang City, Henan Province, China, Jiaozuo, Henan
