China Greentechy Wind Solar Hybrid LED Street Light System,solar and wind Power Street Lights

Items

Solar and wind hybrid street light system

Product picture

(only for reference,standard as the

final finished products)

Solar panel

Mono crystalline silicon power: 130Wp*2

<img src="/img/pb/608/289/579/579289608_727.jpg" alt="High power off-grid hybrid solar and wind LED street light system(High quality best service in China)" width="253" height="191" ori-width="600" ori-height="450">

Wind generator

500W/24VDC*1, starting-up wind speed 3m/s, rated wind speed:8m/s, with 3 pcs blade

Battery

High efficiency, SRS specially design for solar application battery, 12V 100Ah*2

Hybrid Controller

800W/24V, LCD,indoor, over charge , discharge protection,temperature compensation and so on

Solar panel bracket

2×1.2CM angle Iron, hot dip galvanized type, plastic-coating / painting.

Pole

12m, high carbon steel, hot dip galvanized type, plastic-coating / painting.

Lighting source

150W LED lamp, Super Bright LED,130Lm/W, can form 4:1 rectangular shape lighting distribution without Lens or with 120°Beam angle.

cable

4.0mm²×2, SRS specially design for solar application, silicon rubber with purple copper cable.

cabinet

Contain battery and controller, installed in the ground

packing

Cartons / MDF (Middle Density Fiberboard)

Working mode

8 hrs

Reliability

Guarantee 100% lighting throughout the year

Ambient temperature

-20°C~65°C

Payment

50% T/T in advance, 50% balance T/T before delivery.

Quotation validity

30days

Volume

About 0.8CBM/ SET.
