Home > Products > Automotive wire harness protective sleeve > Automotive Sleeving-PPS Braided Expandable Sleeving
Automotive Sleeving-PPS Braided Expandable Sleeving
- Shenzhen
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | JDD TECH | |
| Model Number | FR1080 | Type | Other, sleeve | |
| Material | Other, PPS |
Product Description
Description:
FR1080 V0 PPS expandable braided sleeving is made of PolyPhenylene Sulfide (PPS) monofilament which meet UL94 V-0 standard raw material. It offers high abrasion resistance, chemical resistance, high temperature stability, with low moisture absorption and excellent dimensional stability function.
Application:
It is widely used in the following fields: automotive, railways, aerospace, telecom and military where needs high flame-retardant and high temperature resistance.
Technical data:
Material: PPS
Working temperature: -70℃~ +200℃
Melting point: 285℃±10℃
Flammability: UL94 V-0
Color: Black
Cutting tool: Hot knife
Other feature: acid, solvents and fluid resistant
Dimensions:
Part No. | Nominal size (W) | Expandable Range | Packing (L) | ||
Inch | mm | Min.(I) | Max.(O) | ||
FR1080-003 | 1/8'' | 3 | 1 | 6 | 1000 m |
FR1080-006 | 1/4'' | 6 | 3 | 9 | 500 m |
FR1080-008 | 5/16'' | 8 | 5 | 16 | 350 m |
FR1080-010 | 3/8'' | 10 | 7 | 19 | 350 m |
FR1080-012 | 1/2'' | 12 | 8 | 24 | 350 m |
FR1080-016 | 5/8'' | 16 | 10 | 27 | 250 m |
FR1080-019 | 3/4" | 19 | 14 | 30 | 200 m |
FR1080-025 | 1" | 25 | 18 | 35 | 200 m |
FR1080-032 | 1-1/4" | 32 | 20 | 50 | 150 m |
FR1080-038 | 1-1/2" | 38 | 30 | 60 | 100 m |
FR1080-045 | 1-3/4" | 45 | 35 | 75 | 100 m |
FR1080-050 | 2" | 50 | 40 | 80 | 100 m |
FR1080-064 | 2-1/2" | 64 | 45 | 105 | 100 m |
FR1080-076 | 3" | 76 | 64 | 120 | 100 m |
Unit: mm
