Seamless Stainless Steel U Shaped Pipe

FOB Price

US$ 3,000 - 5,000 / Ton

1 Ton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard	ASTM, AISI, DIN, EN, GB, JIS	Place of Origin	China
Brand Name	Kingmetal	Model Number	EL-UT
Type	Seamless	Steel Grade	300 Series
Application	Heat Exchanger, Heat Exchanger	Certification	ISO
Welding Line Type	Seamless	Thickness	0.5-3mm
Outer Diameter	6-101.6mm

Size:
O. D.: 6mm to 219mm
W. T.: 0.5mm to 3mm
Length: Max. 20meters

Material:

TP304,TP304L,TP304H,TP304/304L,TP316,TP316L,TP316/316L,TP310,TP317, TP317L,TP321,TP321H,TP347,TP347H,S31803,S32205(Duplex),904L etc

Process method: Cold drawn / cold rolled

Surface finish: Annealed & Pickled /Bright Annealed,

180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish and so on.

Standards: ASTM A213,ASTM A312,ASTM A269,ASTM A778,ASTM A790,DIN 17456,DIN 17458,JIS G3459,JIS G3463 etc

Applications:

Stainless steel pipe applies to construction field,

ships building industry, petroleum & chemicalindustries,

war and electricity industries,food processing and

medical industry, boiler heat exchanger,machinery

andhardware fields. Stainless steel pipe can be made

accordingto the customers requirements.

Packing: Seaworthy Wooden Cases / Steel Framed Cases / Bundle

Material	ASTM A213 Chemical Composition % Max
Material	C	Mn	P	S	Si	Cr	Ni	Mo	N B	Nb	Ti
TP304	0.08	2.00	0.045	0.030	1.00	18.0-20.0	8.0-11.0	^	^	^ .	^
TP304L	0.035	2.00	0.045	0.030	1.00	18.0-20.0	8.0-12.0	^	^	^	^
TP316	0.08	2.00	0.045	0.030	1.00	16.0-18.0	10.0-14.0	2.00-3.00	^	^	^
TP316L	0.035 D	2.00	0.045	0.030	1.00	16.0-18.0	10.0-15.0	2.00-3.00	^	^	^
TP321	0.08	2.00	0.045	0.030	1.00	17.0-19.0	9.0-12.0	^	^	^	5C -0.70
TP347	0.08	2.00	0.045	0.030	1.00	17.0-19.0	9.0-12.0			10C -1.10	^
