Home > Products > Graphite product > Graphite Pots
Graphite Pots
- Shanghai
- Credit Card
You May Like
Product Details
| Type | Refractory | Application | melting metal, metallurgy, casting, chemical and (scientific) industry | |
| Height | 78mm-1000mm | Composition | High Pure | |
| Top Diameter | as per customers'request | Bottom Diameter | as per customers'request | |
| Place of Origin | Shanghai, China | Brand Name | Bochuan | |
| Model Number | BC-190 |
Product Description
Specifications
Graphite Pots1.Material:high pure graphite
2.Used for metal melting
3.Long life and good property
Graphite Pots
1.Introduction
The material of graphite crucible can be divided into artificial graphite,clay bonded graphite, and carbon bonded graphite.Artificial graphite crucible is made of graphite electrode as material and made out.
Clay bonded graphite, the main ingredient is natural crystal graphite and clay Now only used in small amount of high-temperature melting of cast iron, cast steel melting and melting of precious metals.
Carbon bonded graphite, the main ingredient is natural crystal graphite and silicon carbide. Mainly used in the melting of the majority of non-ferrous metals such as copper alloy and aluminum alloy
2.Property
a. High thermal conductivity
b.Thermal shock resistance
c.High temperature resistance
d.Corrosion resistance
d. Mechanical shocks resistance
d. Oxidation resistance
e. Anti-adhesive
f. Small metal contamination
g. Good clearner
3. Shapes
standard type,long type,bowl type,lip type, electric furnace type
4.Purpose
melting of copper alloy and light metal alloy
5.Index
Standard parameter | Testing data | ||
Refractoriness ≥ | 1630°C | Refractoriness≥ | 1635°C |
Carbon connent ≥ | 38% | Carbon connent≥ | 41.46% |
Apparent porosity ≤ | 35% | Apparent porosity ≤ | 32% |
Bulk density ≥ | 1.6g/cm3 | Bulk density ≥ | 1.71g/cm3 |
Specification | OD at top | Outer Height | OD at bottom |
1000# | 640 | 773 | 380 |
800# | 630 | 720 | 335 |
500# | 540 | 698 | 313 |
400# | 520 | 648 | 282 |
350# | 485 | 610 | 275 |
300# | 470 | 573 | 240 |
250# | 450 | 550 | 240 |
200# | 398 | 490 | 220 |
150# | 370 | 430 | 192 |
