China Top 10 Manufacturer Portable Conveyor Belt for Conveyor Machine

China Top 10 Manufacturer Portable Conveyor Belt for Conveyor Machine

The following data are for reference only. If you have any needs, please send the Conveyor Belt's CAD/PDF drawings or samples to us, we will produce it according to your requirements.

1-General Conveyer Belt

General conveyor belt is widely used in the metallurgy, building materials, electric power, port, Cement, Fertilizer,mineral mountain, agriculature, etc. Which is suitable for transporting normal temperature non-corrosiveness bulk, granular, powder supplies in general conditions.

Conveyor Belt Features
1.Natural rubber Thin belt body with high strength, light weight;
2.Anti-abrasive, impact resistant, corrosion resistant;
3.Softy belt body, good flexibility, excellent trough;
4.Vulcanization molding;
5.Long service life.

2-Nylon Conveyer Belt and EP Conveyer Belt

Strength specifications of EP/NN convas: 100N/mm 125N/mm 150N/mm 200N/mm 250N/mm 300N/mm 400N/mm etc.

The physical and mechanical properties of nylon conveyer belt and EP conveyer belt are as following:
1. The physical and mechanical properties of coverffig layer: please refer to the physical and mechanical properties of the common conveyer belt.
2. Tensile property of through thickness:
a. The longitudinal tensile strength is not lower than the following nominal value:315 400 500 600 630 8OO 9OO 1000N/mm
b. The total thickness elongation rate of the belt should not less than 10%, the reference force elongation rate of total thickness should no more than 4%.
c. Straightness: no more than 25mm.
d. plunger bond strength:

3-Steel Cord Conveyer Belt
It can be extensively used in the coal, mining, port, metallurgy, power and chemical industries, and is applicable for the conveyance of materials with heavy load, long distance and large freight volume.

4-Corrugated Sidewall Conveyer Belt

Corrugated sidewall conveyor belt always work together with the sidewall transferring system, normally the angle is more than 30°, It also could work together with the general conveying machine for the horizontal and short distance transportation. (Generally, No cleated)

Side wall conveyor belt using baseband that the though degree is more that 0.03,sidewall and cleated(which is not necessary in the horizontal transportation)was made after twice sulfuration.

1.EP/NN /CC/ Steel cord as framework material;
2.Vulcanization molding;
3.Large slope transportation, widely used in bulk material;
4.Saves space, since conveyance at inclines of up to 90° is possible.

5-PVC PVG conveyor belt   Non pressed PVC type is suitable for applications in dry conditions at a slope angle of no greater than 16 degrees. PVG type is suitable for applications at a slope angle of less than 20 degrees.

1. The belt has good flame resistance and anti-static properties .It can fully satisfy the requirements of MT-914 and is especially suitable for material conveying at inflammable or underground coal mines.

 2. The solid woven fabric uses high tensile strength and low elongation polyester long filament as warp fiber, for weft fiber, it uses high tensile and medium modulus nylon filament. The fabric is high in strength, low in elongation, light in carcass, free of separation of plies, shock resistant, anti-tear and good in trough ability.

 3. Non pressed PVC type is suitable for applications in dry conditions at a slope angle of no greater than 16 degrees. PVG type is suitable for applications at a slope angle of less than 20 degrees.

Hebei Juming Import & Export Co.,Ltd is the branch company of Hebei Zhongxin Conveyor Machinery Co., Ltd,which is specially responsible for the overseas business.We could supply our customer with high quality products and the best after-sale service in order to establish the stable and long time business relation with every esteemed company.

Hebei Zhongxin Conveyor Machinery Co., Ltd. is a China-based professional manufacturer of Conveyor Belt and belt conveyor idlers. Established in 1980, our company was primarily engaged in producing and marketing Conveyor Belt, carrying idlers, impact idlers, training idlers, head pulleys, tail pulleys, belt conveyors, and so on.

Our Conveyor Belt Certifications:

OUR CUSTOMERS

Export Market Distribution:

Our Conveyor Belt

Applications

Coal mine, Crushing plant, Grain, Garbage Disposal, Steel mills ...

Our Conveyor Belt

We provide Conveyor Belt OEM service based on the design drawing or the sample. We can also provide any other customized belt conveyor idler rollers on the base of your drawings or original samples.

After sale service:

About Conveyor Belt shipment and sample quality tracking include life time,all your inquiry will be replied within 24 hours by our Customer service professionals.Any questions pleease feel free to contact with us.
