Stepless Frequency Control RFRY Automatic FlexoGraphic Label Printing Machine
- NINGBO
- T/T L/C D/P D/A
You May Like
-
Automatic Die Paper Board Leather Cardboard CREASING AND CUTTING MACHINE
-
Automatic Paper Board Leather Cardboard CREASING AND CUTTING MACHINE
-
Automatic Paper Board Leather CREASING AND CUTTING MACHINE
-
Automatic Paper Board CREASING AND CUTTING MACHINE
-
Automatic Paper CREASING AND CUTTING MACHINE
-
Automatic Plastic Film Food Drinking Straw Dishes Packaging Machine
Product Details
| Condition | New | Plate Type | Other, Flexographic Printer | |
| Place of Origin | Zhejiang, China | Brand Name | TINVA | |
| Model Number | RFRY | Usage | Label Printer | |
| Automatic Grade | Automatic | Certification | CE ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
RFRY Automatic FlexoGraphic Printing Macine
Characteristics
1. The main motor adopts imported converter to govern in a stepples way.
2. Feeding and discharging are controlled through magnetic powder brake and clutch (Japanese Mitsubishi aut tension controller).
3. Unwinder system is controlled by auto-rectify sensor.
4. Adopt ceramic anliox roller, which is characterized by durability, wear resistance, and corrosion resistance, which is more efficient for reducing the times for changing in order to increase the production efficiency.
5. The printing unit can register in 360 degrees. Each printing unit can indepen dently gear and loosen to have the units continue printing.
6. The printing units are all equipped with a group of infrared dryers respectively.
7. Each IR dryer device of printing unit can interchange of UV dryer device.
8. Unwinder and rewinder are adopted clipping device with air shaft.
9. The inking roller can automatically fall off at stoppage and transfer at low speed in order to keep the ink from being dry and solid.
10. The roll feeding, printing, UV vanish, auto infrared drying, laminating and rewinder can be processed in one processing. It is characterized by wide application, non-population of printing ink and fast drying, quick printing. So it is an ideal printing machine for the commercial bill to print high-Gradded free adhesive trademark.
| Printing speed | 60m/min |
Color | 5colr (or up to buyers request) |
Web maximum width | 320mm |
The largest printing width | 310mm |
Roll diameter | 600mm |
Rolling diameter | 550mm |
Printing perimeter | 175~320mm |
Alignment accuracy | +/-0.1mm |
Dimension | 2000*1500*3000mm |
Weight | About 2000kg |
Power supply | 380v/AC 3phase 50Hz |
Total power | 6.8kw (UV is not included) |
Machine
Sample
1. Installation Service
- Installation Services are available with all customers.
- we can send our Enginner to your company to install the machines If customer needs.
2. Training Service
- We can train your staffs how to run the machine efficiently and safely.
3. After Sales Service
- Guaranty: One Year and offer the lifetime maintenance service.
- During warranty period and after warranty period, We will come for regular checks on machine and make records to ensure the normal operation of equipment.
- Our experienced engineer are always available for dispatching abroad to help customers.
- Any question, welcome to contact us at any time
) ISO 9001:2000; CE, TUV production assessment , gold supplier certificated
2) we obtained many machine Patent
3) machines meet to Europe Exporting requirements , and has exported to UK , USA ,POLAND and so on .
4) all machines will be examined and test before delivery .
5) we have more than 16 years experience on machines , and I have many years experience on do international trade , will offer you skillful knowledge and after-sales services.
6) perfect after-sale system ,details refer to PI
7) prompt reply within 12 hours
1. Q: Are you a factory or trading company?
A: we are a factory
2. Q: where is your factory located ? How can I visited there ?
A: our factory is located in Ruian City , Zhejiang Province,China.
about 40 minutes by plane from shanghai ( 5hours by train )
If needed , It is my pleasure to pick up you , and book hotel room for you .
3. Q: How Can I get some samples?
A: we are honored to offer you samples
RUIAN RUIFENG PACKING MACHINE CO.,LTD.
ADD: NO.4,Guangming Road,Shibajia Industrial Area,Rui’an City,
Zhejiang Province, China, zip code 325200
Tel:86-577-66800288
Mobile:0086-18966252819
Fax:86-577-65885280
Skype:rfpack
