Low Price Best Seller Factory Price Feed Pellet Machine for Animal

Specifications

China factory outlet of  feed pellet machine for animal

Introduction of feed pellet machine for animal :

Our feed pellet machine for animal use sawdust, crop stalks (corn stalk, big haulm, sorghum stalk, cotton, rape stalk, peanut seedling, sunflower stalk), chaff, grasses, shrubs, bamboo cutter head, bamboo shavings, bagasse as raw material, such as using native high temperature extrusion into particles.The finished product and cylindrical.Also can be made into spherical, particle shape, honeycomb briquet.

1.The machine is the new-designed products of our company and the main parts of the fodder machinery system.They widely used in feed factories, breed aquatics factories, organic fertilizer factories, chemical factories, and China traditional medicine factories, etc.It can be used together with powder material. Its capacity is superior in the same industry home and abroad.

2.The machine has such characters as compact structure, beautiful outline, high output, low energy loss, convenient operation, and reliable capacity etc.

3.Our company supply many different ring dies, such as φ2, φ3, φ4, φ4.5, φ5, φ6, φ8, φ10. It can be chosen according to different requirements.

4.Pellet application: as feed for animals and poultry like pig, cattle, goat, fish, shrimp and pets etc.  pellet feed machine. pellet feed press machine. pellet feed extrusion machine.

5.Driven by gear .more strong than by belt, and the capacity 10% higher than by belt .

6.The machine also matched the safty equipment , once overload , the safty pin will crack, to protecting the machine lifetime.

7.The machine has adopted gradeless speed-adjusting motor to feed and installed ferromagnetic magnet system, overload protection device and a limit switch to make sure the security.

Besides, there are outer pellet-discharged structure and pressure or oil pump lubricant system.

Working principle of feed pellet machine for animal :

Our pellet machine between the mould and roller extrusion die and friction interaction principle,

make the molding material to be acquired . Material need not add any additives or binder in the

machining process, Straw materials contain a certain number of cellulose and lignin, The lignin is the

material structure of the monomer, belongs to the benzene propane type polymer compounds. Can

strengthen the cell wall, together with the role of the cellulose, Lignin belong to amorphous,does not

dissolve in any solvent at room temperature, without melting point, but there have softening point.

When the temperature reaches a certain, the lignin to soften the cohesive force, and under certain

pressure, make its cellulose molecular mass displacement and deformation and extension, Biomass

particles within adjacent to connect each other, reassembled and pressure molding.

Main features of  feed pellet machine for animal :

♦ Advanced belt-driving system with double motors on animal feed pellet machine, stable and reliable.

♦ Adopting high-qualified components on animal feed pellet machine, with long service life and low cost

♦ Whole transmission parts (including motor) of animal feed pellet machine chooses high-quality NSK/SKF bearings to ensure the transmission efficient, stable, low noise. Main motor choose Siemens.

♦ This animal feed pellet machine is equipped with full single layer stainless steel conditioner, ring die and cutter.

♦ Optional parts: Animal feed pellet machine can be equipped with double jackets stainless steel conditioner and dual spindle differential conditioner according to demands.

♦ A variety of overload protection devices and warning signs on animal feed pellet machine.

♦ Structural alloy steel main shaft with good strength and toughness.

Structures of  feed pellet machine for animal :

(1)Main drive adopts high-precision gear drive , the ring mold with advanced quick detachable hoop type , yield 20% higher than the belt drive around.
(2)Machine transmission parts ( including motor) with Swiss ring die pellet machine sawdust and Japanese high quality bearings ensure transmission efficiency, stability and low noise.
(3)Adopt international advanced level of German gun drill and vacuum furnace heat treatment manufacturing process, from the processing of high-quality alloy steel ring mold , long life, smooth out the grain , high quality .
(4)The international advanced level of power transmission couplings, sawdust fuel pellet machine has a novel structure , compact, safe , low noise , low failure performance.
(5)High performance permanent magnet device.
(6)All stainless steel door and chute with scale line stretching cutter , the cutter easy to adjust , and reliable.

Installation and technical service:

To ensure the machine good working in customer site, it is suggested that customer send workers to accept the training about how to work with machine, how to solve frequently asked

problems, how to replace spares etc. In this way can we ensure the good working and give

warranty of 1 year for the machine. Or we can send you our technician to customer side to help

customer set up the machine and train your workers.
