Home > Products > WiFi Wireless Monitor > Built-in Wifi Wireless Rear View Reverse Camera HD 7" Monitor for Truck Trailer No Interference Guarantee
Built-in Wifi Wireless Rear View Reverse Camera HD 7" Monitor for Truck Trailer No Interference Guarantee
- 10000 Unit / Units per Month
- shenzhen
- Credit Card PayPal
You May Like
-
WIFI wireless 9" TFT LCD Color 2 Video Input Car RearView Headrest Monitor DVD VCR Monitor With Remote and Stand & Support Rota
-
WIFI wireless 9 inch TFT LCD color2 video input car rear view monitor DVD VCR Monitor with Remote and stand
-
WIFI wireless Auto Safe Driving Combo:9 Inch TFT LCD Digital Car Rear View Monitor + Car Rear View Camera Security Backup System
-
5.0 inch car DVR + Android 4.4 +3 cameras + dual recording + radar detector + GPS navigation + Wifi access
-
1 set Wireless Truck bus parking system with IR Night vision camera + 7 inch LCD Monitor kit trailer van bus Rearview Reverse
-
7" HD Car TFT LCD Color Touch Screen Monitor Rearview Display Backup Camera Monitor System for Truck Trailer Bus Video Input
Product Details
Certification | CE | Place of Origin | Guangdong, China | |
Brand Name | windrunner | Model Number | WR-MNT5700, WR-MNT5010 | |
Warranty | 12 Months |
Product Description
Built-in Wifi Wireless Rear View Reverse Camera HD 7" Monitor for Truck Trailer No Interference Guarantee
*WIFI transmission, good data security
*Wireless, easy installation within minutes
*One second startup, no signal delay, safer driving
*No interference, good performance among other wireless devices.
Wifi Video Camera
TV System | NTSC/PAL(Factory Fixed) |
Transfer Range | 120m(open side) |
Startup Time | About one second |
Transfer Resolution | 640x480(VGA) up to 30fps |
Video Compression | MJPEG |
RF Frequency | 2.4GHz ISM Band |
Wireless Standard | WiFi 802.11b/g/n |
Data Transfer Rate | 1,2,5,6,11,12,18,22,24,30,36,48,54,60,90,120 and maximum of 150Mbps |
Modulation Method | BPSK/QPSK/16-QAM/64-QAM |
Spread Spectrum | IEEE 802.11b: DSSS(Direct Sequence Spread Spectrum) |
IEEE 802.11g/n: OFDM(Orthogonal Frequency Division Multiplexing) | |
Video Input/Output | 1Vp-p Composite |
Operating Current | 120mA@w/o IR; Max 300mA@w/i IR on; |
Connectors | TBD, Ext ANT |
Transimitting Power | 18dBm@11b, 15dBm@11g, 13dBm@11n. |
Sensor image | 1/4" CMOS ASX340 |
Operating Temperature | -20℃~ +70℃ |
Storage Temperature | -40℃~ +85℃ |
Operating Humidity | 10% ~ 90%Rh |
Input Voltage | DC 9V-36V |
Dimensions | W:40mm, H:6mm, L:70mm |
7inch Wifi Monitor
Screen Size | 7.0 inch digital TFT panel |
Display Resolution | 800*R.G.B*480 |
Display Mode | 16:9 |
Contrast | 350:1 |
Multi languages | English,Chinese |
TV System | NTSC/PAL(Factory Fixed) |
Transfer Range | 120m(open side) |
Startup Time | About one second |
Transfer Resolution | 640x480(VGA) up to 30fps |
Video Compression | MJPEG |
RF Frequency | 2.4GHz ISM Band |
Wireless Standard | WiFi 802.11b/g/n |
Data Transfer Rate | 1,2,5,6,11,12,18,22,24,30,36,48,54,60,90,120 and maximum of 150Mbps |
Sensitivity | 11Mbps -83dBm@8%, 54Mbps -73dBm@10%, 130Mbps -64dBm@10% |
Modulation Method | BPSK/QPSK/16-QAM/64-QAM |
Spread Spectrum | IEEE 802.11b: DSSS(Direct Sequence Spread Spectrum) |
IEEE 802.11g/n: OFDM(Orthogonal Frequency Division Multiplexing) | |
Video Input/Output | 1Vp-p Composite |
Operating Temperature | -20℃~ +70℃ |
Storage Temperature | -40℃~ +85℃ |
Operating Humidity | 10% ~ 90%Rh |
Input Voltage | DC 6V-24V |
Operating Current | 110mA |
Dimensions | W:120mm, H:25mm, L:180mm. |
1) Efficient after-sales service within 24 hours;
2) OEM&ODM
3) Protection of your design & product info;
4) CE, FCC
Shenzhen Windrunner Technology Co. Ltd. is a pioneer in Wifi Wireless Vehicle backup system with DVR, GPS Navigation, Radar detector, Bluetooth etc.
"Fashion, cutting-edge, practical and convenient" is our goal.
We are fortunate to develop a series of “shocking the industry” products, such as wifi wireless car DVR rearview mirror (with GPS navigation), wireless reverse monitor with built-in wifi etc.
Your satisfaction inspires us to continue our innovation in the Wifi Wireless Car Cameras, and we will continue to launch more surprising products for you!
1.What about the warranty?
12 months.
2.How to use the car rearview mirror?
This is innovative product based on WIFI transmission; wire free, very easy to install and operate.
Please follow the instruction & maintenance guidelines.
3.What's the payment and the delivery time?
- Mastercard, TT, Paypal, Western Union, Escrow, LC are acceptable;
- Normally, a lead time of 3-7 business days (based on quantity); DHL, Fedex, UPS, TNT.
Contact Us
- Shenzhen Windrunner Technology Co., Ltd.
- Contact namefrancis li Chat Now
- Phone86-0755-83246648
- AddressRoom 2406, Nanguang Jiejia Building, Shennan Middle Rd., Shenzhen, Guangdong
