Home > Products > Oil Mining Equipment > High Pressure and Anti-sulfide Wellhead & X-Mas Tree
High Pressure and Anti-sulfide Wellhead & X-Mas Tree
- China main port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | China | Brand Name | Senwell | |
| Certification | API |
Product Description
Specifications
The product is mainly used for deep of ultra deep wells or high pressure wellsStandard: API SPEC 6A standard.
Technical specifications and parameters for High Pressure and Anti-sulfide Wellhead & X-Mas Tree | |||
Type | KQ78/65-105 | KQ65-70 | KQ65-70 |
Nominal diameter | 3 1/16” | 2 9/16” | 3 1/16” |
Max. working pressure | 15000psi | 10000psi | 10000psi |
Working Temperature | -20 °F~250 °F | -20 °F~250 °F | -20 °F~250 °F |
Working Medium | Crude oil, Natural gas | ||
Main Valve | PF105-78 | PF70-65 | PF70-78 |
Wing Valve | PF105-65 | PF70-65 | PF70-78 |
Side way Valve | PF105-65 | PF70-65 | PF70-78 |
Upper flange of tubing head | 7 1/16~15000 | 7 1/16~10000 | 7 1/16~10000 |
Bottom flange of tubing head | 7 1/16~15000 | 7 1/16~10000 | 7 1/16~10000 |
