200T G Series Variable Pump Injection Molding Machine for Thin-wall Products
Negotiable
/ Set
1 Set(Min. Order)
- Guangzhou/Shenzhen
- T/T
You May Like
-
330T Variable Pump Injection Molding Machine for Thin-wall Products
-
PET Preform Injection Molding Machine (PET-500V2)
-
5 Gallon Preform Making Machine (PET-1200V2)
-
Automatic PET preform making machine (PET-1505V2)
-
330T CE Approved Energy-saving Injection Molding Machine
-
288T ISO9001 Approved Energy-saving Injection Molding Machine
Product Details
| Condition | New | Type | Tube Head Injection | |
| Style | Horizontal | Brand Name | Powerjet | |
| Model Number | GZ-208 | Place of Origin | Guangdong, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 383-651g | Injection Rate | 483-822g/s | |
| Clamping Force | 2000KN | Opening Stroke | 490mm | |
| Power(W) | 30KW+11.5KW | Certification | CE/ISO9001 |
Product Description
Specifications
Nitrogen injection with accumulateor achieves injection speed over 350m/s.| PARAMETER OF GZ-208 | ||
| DESCRIPTION | UNIT | GZ-208 |
| CLAMPING UNIT | ||
| Clamping force | KN | 2000 |
| Opening stroke | mm | 490 |
| Max.daylight | mm | 1040 |
| Platen size | mm×mm | 775x755 |
| Space between Bars(H*V) | mm×mm | 510x510 |
| Max. Mold Height | mm | 550 |
| Min. Mold Height | mm | 230 |
| Ejector Stoke | mm | 140 |
| Ejector Force | KN | 65 |
| INJECTION UNIT | ||
| Screw Diameter | mm | 46 52 60 |
| Screw L/D Ratio | 21.7 19.2 17.5 | |
| Injection Pressure | Mpa | 201 157 118 |
| Shot Volume | cm³ | 407 520 693 |
| Shot Weight(PS) | g | 383 489 651 |
| Injection rate | g/s | 483 617 822 |
| Screw Stroke | mm | 245 |
| Screw Speed | RPM | 274 |
| POWER UNIT | ||
| Hydraulic system pressure | MPa | 16 |
| Pump motor power | KW | 30 |
| Heater power | KW | 11.5 |
| GENERAL | ||
| Oil tank capacity | L | 420 |
| Machine weight | Ton | 5.8 |
| Machine dimensions(l×w×h) | m×m×m | 5.8x1.5x2.1 |
Production Instance
750cc square fast food box
Cavity:2
Thickness:0.43mm
Weight:19g
Cycle time:5.3s
Material:PP
