red brick machine

Specifications

 red brick machine

         This     red brick machine is small investment, the function, high efficiency, high degree of automation, is well received by the customers like it.

technical parameters of cement brick machine cost

The molding cycle                   10 to 15 seconds/time

Design production capacity       6000 pieces/class  3 piece/mold

The vibration frequency           4600 times per minute - 6100 times/min

The excitation material            22 kn

Vibrator                                 6 kw power

oil pump                               About Cb32 flat   Q = 40 ml/r p = 10 mpa

Oil cylinder                            80 x300   pole size 40

Cylinder                                 63 x250   pole size 40

Hydraulic system pressure rated   27.5 million mpa

The installed capacity               17.95 kw

plate specifications                   750 mmx530mmx30mm

The weight                             4.5 tons

Dimension                             6100 mmx3600mmx2650mm

Production technology and ingredients of cement brick machine cost

1. The production area should more than 300 square meters, factory building could be   (8 m *15m) 100-200 square, and three-phase power source is need.

2. The first thing to prepare is some plate in order to use brick,which can use the old template, bamboo veneer cutting. Plate specification: 750*530*30mm, quantity: 600-1000.

3. A better quality of cement used no. 325 or 425 cement, conditional can prepare some fly ash, fine fine stone, coarse sand within 0.5. Also can be directly use stone powder, it has served the less fine stone grain.

If you need please feel free to contact me at any time
