JL-1 Paper Edge Protector Production line for corrugated box machine
- tianjin
- T/T
You May Like
-
JL-1 Paper Corner Protector Machine High Quality Round Edge Protector Wrap Paper Corner Machine
-
JL-1 High Speed Paper Edge Protector Making Machine
-
JL-1 paper edge protector making machine for hot product in china
-
JL-1 Paper Edge Board machine for making edge protector
-
JL-1 Brand New U Shaped Paper Board Edge Protectors Machine
-
JL-1 paper edge protector machine/ paper protector making machine/ paper corner machine
Product Details
Condition | New | Function | Other, producing paper corner | |
Application | Beverage, Chemical, Other, Beverage, Chemical, Machinery & Hardware | Packaging Type | Film | |
Packaging Material | Plastic | Automatic Grade | Automatic | |
Driven Type | Electric | Voltage | 380V | |
Power | 11KW | Place of Origin | Hebei, China | |
Brand Name | JIALONG | Model Number | JL-1 | |
Dimension(L*W*H) | 22000x1400x2300 | Certification | CE/ISO9001 | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Technique parameter:
|
High speed model |
Three-use model | |
| technoligy | technoligy | |
1 | type | L |
|
1 |
Edge board size | 20-130mm (one side size) | L: 20-130mm U: 20-70mm(each side) Flat board:40-150mm |
2 |
Maximum speed | 50m/min | 30m/min. |
3 |
Common speed | 20-40m/min | 15-25m/min. |
4 |
Synchronize cutting |
Synchronize by servo motor | |
5 |
Cutting power |
Servo motor& cam drive | |
6 |
Cut precision | ±1mm | |
7 |
Max. Layers of paper | 12 | |
8 |
Glue feeding system |
Dia-pump(imported) automatic feeding the glue (recycle) | |
9 |
Dimension (mm) | 22000×1400×2300mm | 25000×1400×2300mm |
10 |
Gross weight | 3000kg | 3500kg |
11 |
Applicable paper | core paper:420gsm sand paper face paper :180-300gsm Kraft paper | |
12 |
Motor power | 11kw |
Jialong Packaging Machinery Co.,Ltd is a academician of Chinese Packaging Technic Association.Our company specializes in discovery, development and production of corrugated cardboard production line, automatic flexo ink printing slotting die cutting machine, semi-autoatic flexo ink printing slotting machine,auto rotary die cutting machine ,single facer corrugator machine, flute laminating machine, automatic carton folder gluer machine,carton stitching machine, slotting machine, thin blade slitter scorer machine, egg tray making machine, paper edge protector making machine, paper tube core making machine and other relevant packaging machinery.
Many years before, our company considers “Quality is first, Honesty is root” as our principal, to meet customers’ demand is our target. We can supply from machine design to after-sale all service with high quality and professional technique.
We would like to cooperate with friend from every countries sincerely, and we will work hard to create the future of package together
After Sales Service
We deeply know that, excellent and effcient after-sales service is an indispensable part for clients to achieve due benefits. To offer most favourable and satisfactory service for wide clients, we hereby solemnly promise:
fessional technicians will be assigned to client's site to give guidance in equipment installation and commissioning and hole training class for operators;we also offer charge-free training in our company for operators and maintenance personnel if requsted by clients.
2.The equipments will be delivered accompanied with detailed installation and operation manual and related information. Upon client's request,we can also offer plant layout design by free of charge.
3.All the equipments are offered with one year quality warranty. within the warranty period, maintenance of equipment and replacement of wearing parts are charge-free.Affer the guarantee is expired, we offer long-term maintenance service and supply of parts and components at cost price. Clinets Complaint: A speacias round-clock fax will receive your complaints seriously. We will response within 24 to 48 hours affer receiving your complaints by phone call or going to site.
