HB-1600 type cutting machine slitting big roll to small roll

HB-1600 type cutting machine slitting big roll to small roll

Features:

Equipped with photoelectric tracking. Auto adjustment. Tension control and operation indicator. The cutter can be operated in a simple way with a reliable function. The machine can be complied in splitting cutting of plastic film, medical film paper and medical paper etc.

  Technical Parameter

1.6m Specification of machine:

Introduction:

This machine is used for slitting non-woven fabric, Fabric, Paper,Plastic film and some filmy roll material. Easy operation, energy efficient, saves space for setting. It is a good and ideal machine for slitting non-woven fabric.

Parameter:

Unwinding length: 1600mm
Max.diameter of unwinding: 800mm
Max.diameter of rewinding:800mm
Slitting size: minimum 30mm
Speed: 20—80m/minute

Total power: 2.2kw

Power Supply:220v

50Hz
Weight: 500kg

Overall dimension (l*w*h):2800mm*1500mm*1500mm

Configuration:

Slitting machine (slitter one big roll into small roll)

Unwinding materials: unwinding material fixed by air cylinder

Unwinding material: left and right could be adjusted.

Rewinding tension adopt 5kg magnetic powder brake, rewinding up and down

Cutter: 30 pieces
Edge correction motor: meifeng
Converter motor: kewo

Electrical: chint
Pneumatic: SNS

Magnetic powder: shengda

Spare parts:
socket wrench   monkey wrench   screwdriver   oil gun   panel switch    knife: 30
