2016 New Designed Road Planing Machine

FOB Price

USD $2,800 - $3,200 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Working Width	Customized
Working Depth	<= 25mm	Place of Origin	Hebei, China
Brand Name	HT	Model Number	WC-400
Voltage	Diesel Engine	Power(W)	8.05Kw
Dimension(LWH)	1700x950x830mm	Weight	300kg
Certification	ISO	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

2016 First Clas Road Planing Machine :

Application And Features :

1 This product is an indispensable tool for building concrete pavement, widely used in building cement pavement, venues, airports, bridges, docks.

2 It is suitable for the mud road, roads, airport runways and other non-slip surface engraved slot.

3 Replacing the old tradition of suppression of non-slip method which uses plastic brush, broom, napping machine.

4 After grooved by this machine,the road surface is slip-proof, durable, smooth surface, both beautiful and generous.

Technical Parameters:

Model	WC-400
The Power Of Main Motor	7.5 kw
The Power Of Walking Motor	0.55 kw
The Rotary Speed Of Blade	2930 r/min
Depth Of Grooving	less than 25mm
Width Of Single Grooving	according to client’s requirement
The Diameter Of Blade	according to client’s requirement
Total Grooving Width One Time	400 mm
Working Speed	1.76 m/min (1 gear) 2.34 m/min (2 gear) 3.14 m/min (3 gear)
