FY-PS Factory Design SPCC Electrical Control Box

Specifications

FY-PS Factory Design SPCC Electrical Control Box

Features & Specifications:

1. The frame is made of nine folds profile and welded by special 3-Tees .The whole structure is stable and the appearance is exqusite.

2. Door panel with internal stiffeners and punched with round holes per 25mm, enhancing door strength, meanwhile enabling easy installation of wiring harness and electronics components etc.

3. Installing panel can be easily moved forward & backward, the installation depth is adjustable( take 25mm as unit).

4. Installing panel can adopt rotary switch design, with two small round lock for fixing, making it convenient for installing electronics components.

5. The top cover, rear door, side panels and bottom panel are all fixed by screws, easy for installing and uninstalling, ensuring convenient inner installation.

6. Cable entries designed on bottom panel, with three-part cover which can move flexibly, easy to input cables. Optional punching holes for cable entry available.

7. Door hinges are interchangeable. Front door adopts automatic gluing or sealing tapes, the door fork with three-point locking system, ensuring reliable sealing. IP degree: IP 54.

8. Customizations based on customer requirements are welcomed; various kinds of specifications and structure adjustment are available.

Surface treatment:

Degreasing, Pickling, Phosphating, Cleaning, Drying, Powder coating or Stainless drawbench

Material:

SUS stainess steel; High quality SPCC (cold rolled steel)

Thickness:

Installing panel:2.0mm-2.5mm;

other: 1.2mm-2.0mm

Surface color (optional):

RAL 7035 (Grey); Orange colored Installing panel or Hot galvanized plate

Some pictures of the industrial electric control cabinet:

FY-PS Series industrial electric control cabinet structure view:

 Some pictures of our factory & certificates:
