3 Horse Float Tandem Axles Truck Trailer

FOB Price

US$ 8,000 - 10,000 / Set

1 Set(Min. Order)

Port Tsingtao
Payment TermsT/T D/P D/A Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

OEM No.	3HAL-L500	Max Payload	2500KG
Size	5925 x 2290 x 2600mm	Place of Origin	Shandong, China
Brand Name	Standard	Model Number	STD-3HAL-L500

Product Description

Specifications

1.Hot dip galvanized whole chassis
2.Different float use different tyres
3.50*50 axles making the trailer more strong.

Specifications:

Model	STD-3HAL-L500
Materials	Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)
	Frame Material: double hot dip galvanized RHS (2.5mm)
	Body Panel: galvanized sheet (1-1.5mm)
	Roof: Special molded FRP 3mm
Brake	double axle electric brakes
Drawbar	Drawbar Checker Plate 1.2mm aluminium
	Drawbar Safety Chain two & Bracing Wheel one
Suspension	Roll rocker tandem spring 8 plate
Axles	*Two special trailer axles 5050mm**
Wheels & Tyre	Five 205R14 tyres and 14’ aluminum alloy rims including a spare wheel
Rubber Matting	18mm special plywood for floor& ramp door
	Rubber Matting For Inner Side Panel 6mm Rubber Matting
	Rubber Matting For Floor & Ramp Door 17.5mm anti-slip rubber sheet
Windows& Doors	*Front Window (mm) 1220610mm**
	Side Windows 6 Drop-down windows 3
	Vents two large size upturning ventilation windows
	*Rear Upper Door (mm) 19801065 Strut & High-intensity anti-rust strut**
	*Ramp Door (mm) 20301210**
	*Side Door (mm) 1730615**
	Hinges for Rear Upper Door special 6mm diameter copper hinges
Supporting Wheel	Swing-able knight supporting wheels to make parking safe and reliable
Lights& Retro Reflectors	Trailer Plug Seven-prongs plug
	Rear Lights brackets aluminium
	LED interior lights, two small LED sidelights, two LED combination taillights
	Retro Reflectors 8
Auxiliary Fittings	Cupboard Front
	Horse Protection Frame fully padded
	Horse Ring 7
	Saddle Rack in saddle box(1200mm height for 3 saddles)
	Rug Rack Side
	Saddle Box One
Dimensions	Body Dimension (L x W x H: mm) : 5075 x 1980 x 2230
	Inner Dimension (L x W x H: mm) : 5025 x 1930 x 2155
	Overall Dimension (L x W x H: mm): 5925 x 2290 x 2600
	Length of Tone (mm): 850
Empty Weight	1900 KGs
Carrying Capacity	2500 KGs
