2 Horse Floats Straight Load for Australia Standard

Model

STD-2HSL-S

Materials

Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)

Frame Material: double hot dip galvanized RHS (2.5mm)

Body Panel: galvanized sheet (1.0&1.5mm)

Roof: Special molded FRP

Brake

Perfect security structure design, double axle electric brakes

Draw bar

Drawbar 1.2 mm checkplate

Drawbar Safety Chain two & Bracing Wheel one

Suspension

Roll rocker tandem spring 5 plate

Axles

Two special trailer axles 50*50 mm

Wheels & Tires

Five 185R14C tires and aluminum alloy rims, including a spare tire

Floor & Rubber Matting

18mm special solid wood floor and all anti-slip rubber floor

Rubber Matting For Inner Side Panel     6mm Rubber Matting

Rubber Matting For Ramp Door   10mm Rubber Matting

Rubber Matting For Floor     17mm Rubber Matting

Pedal &Aluminum Step

1.2mm Aluminum decoration board

Mudguard

Mudguard 1.2mm Aluminum checker plate

Windows & Doors

Front Window (mm) 1220*610

Side Windows   one on each side 900*300

Vents     two large size upturning ventilation windows

Front exit (mm) widthxheight 850*2200

Rear Upper Door (mm) 1750*1065

Ramp Door (mm) 1800*1210

Side Door (mm) 1730*615

Rear Upper Door & Ramp Door Strut   High-intensity anti-rust strut

Hinges for Rear Upper Door   special 6mm diameter copper hinges

Supporting Wheel

Swing-able knight supporting wheels to make parking safe and reliable

Lights

An LED interior light, two small LED sidelights, two LED combination taillights and one LED number plate light

Trailer Plug   Seven-prongs Plug

Auxiliary Fittings

Cupboard       Available

Horse Ring     Four

Saddle Box   none

Saddle Rack ( Available in the front opening saddle door)

Rug Rack   Available

Dimensions

Body Dimension (L x W x H :mm) : 3075 x1750 x 2230

Inner Dimension (L x W x H:mm) : 3025x 1700 x 2155

Overall Dim.(L x W x H:mm) :3925x2290x2600

Length of Tone (mm)     850

Empty Weight

1200 KGs

Max Payload

1500 KGs
