LCD Display Communication Radio Marine DSC Transceiver

FOB Price

US$ 1 - 100 / Acre

1 Acre(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

China

Brand Name

Bochi

LCD Display Communication Radio Marine DSC Transceiver

Product Description

1. Equipped with all international channels. (with United States and Canada channels)

2. High transmission power of 25W / Low transmission power of 1W.

3. Principal commands duplicated on the microphone.

4. Back lit LCD display and adjustable contrast.

5. Possibility to program 20 private channels.

6. Extraordinary capability for water resistance. Conforms to the standard IPX7.

7. Recall button for channel 16.

8. NMEA connection from the transceiver to an external GPS system.

9. DSC or Digital Selective Calling.

10. MMSI directory.

11. Mounting on adjustable bracket.

12. Connection to an external speaker.

1. Channels	All 57 international marine channels
2. Frequency generation	PLL synthesizer
3. Frequency range	TX from 156.025 to 157.425 MHz RX from 156.300 to 162.000
4. Antenna Impedance	50 Ohm
5. Power Supply	12 Vdc
6. Operating Temperature	from -15 degrees Celsius to +55 degrees Celsius
7. Size	72x177x146 mm
8. Weight (device only)	1.380 kg

TRANSMITTER
1. Output power	High (HI): 25W / Low (LO): 1W
2. Modulation type	FM
3. Microphone	Condenser type
4. Hum and Noise attenuation	34 dB
5. Audio distortion	<5%
6. Harmonics reduction	<36 dBm

RECEIVER
1. Sensitivity @ 20 dB Sinad	<0.5 UV
2. S/N ratio (20 dB)	0.8 UV
3. Squelch sensitivity	Threshold -12 dB UV (EMF)
4. Adjacent channel rejection	70 dB
5. Audio output power	> 2W 8 Ohm
6. Audio distortion	10%
