electrical socket American type PDU socket for cabinet
- Ningbo
- Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | XD | |
| Model Number | UKS07-1.5U | Type | Plug with Socket | |
| Grounding | Standard Grounding | Rated Voltage | 250V | |
| Rated Current | 16A | Application | Other |
Product Description
Specifications
1) Number of sockets:72) Uninflammable PC module, Aluminium alloy shell
3) Certificate: CE,RoHS
4) With Surge protector
American type PDU
Detailed Product Description
American Power Distribution Unit
1) Number of sockets:8
2) Uninflammable PC module, Aluminium alloy shell
3) Certificate: CE,RoHS
4) With Surge protector
American Power Distribution Unit
Pating and principal characteristics classification
Rated current | 16A |
Rated load | 3500W |
Rated voltage | 250V |
Household voltage | 230V |
Number of sockets | 7 ways |
Size | 19" 1.5U |
Shell material | Uninflammable PC module, Aluminium alloy shell |
Type of cable | H05VV-F3G1.5mm2×2.15m |
Type of plug | VDE16A plug |
Degree of protection against electric shock | IP20 |
Provision for earthing | With earting contact |
Method of connecting the cable | Non-rewirable |
Type of connections | Welded-solder |
Degree of protection against electric shock | Normal protection |
Existence of shutters | With shutters |
Method of application-mounting | Portable type |
Other items you can search according following method of item number
Packaging Details
Carton size | 54*40*20 |
Product box size | 52.5*7.5*5.5 |
Quantity in one carton | 10pcs |
Metal enclosure | |
Gross weight for one carton | 15kg |
Net Weight for one carton | 14kg |
Plastic enclosure | |
Gross weight for one carton | 10kg |
Net Weight for one carton | 9kg |
