High efficiency water turbine

FOB Price

US$ 15,000 - 1,000,000 / Unit

1 Unit(Min. Order)

Port China Port
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	Bochi
Model Number	water turbine		Type	Other, Hydropower Equipments

Product Description

Specifications

1.water turbine power: 20kw~250Mw
2.Frequency: 50hz or 60hz
3.Output Type: AC three phase
4.Output voltage:400V, 6.3KV, etc

	Alibaba Recommended Supplier Alibaba Excellent Supplier

1.Power: 20kw~250Mw
2.Frequency: 50hz or 60hz
3.Output Type: AC three phase
4.Output voltage:400V, 3.3KV, 6.3KV, 10.5KV, or 13.8KV
5.Bochi's turbine working Water head range:
for Francis type 15~450m
for Pelton type 80-1200m
for Kaplan type 2~65m
for Tubular type 1.8~25m
for Turgo type 35-150m
6.Warranty period: 1 year(or more)
7.Lifespan: 30~50years

High efficience Medium and Small Hydro Power water turbine / hydro turbine(Kaplan turbine, Francis turbine, Pelton turbine, Turgo turbine, and Tubular turbine) / hydroelectric generator with range 20kw-250MW per unit; vertical and herizontal type are available
Offer all types of generators, turbines, hydropower equipment, complete set of hydropower and other power plants, etc.
Equipments would be produced according your request!
Engineers for erection and commission at hydropower plant are available!
There should be some key parameters (such as head, flow discharge and capacity, if need turbine generator too, please supply the frequency and output voltage, if not, give us the rotation speed) in inquiry.
Note: Bochi can design and manufacture various types of hydro generator units with 0.42-7m in turbine runner diameter and 20KW-200MW in unit capacity, such as Tubular type, Axial(Kaplan) type, Francis type, Inclined jet(Turgo) type and Impulse(Pelton) type ones, and auxiliary equipments.

Production Capacity
Product Name		Production Line Capacity			Actual Units Produced (Previous Year)
Kaplan Turbine		35 Sets Per Year			5 Sets
Francis Turbine		65 Sets Per Year			9 Sets
Pelton Turbine		25 Sets Per Year			4 Sets
Turgo Turbine		12 Sets Per Year			3 Sets
Speed Governor		60 Sets Per Year			8 Sets
Surge Valve		20 Sets Per Year			5 Sets
Production Machinery
Machine Name	Brand & Model No.		Quantity	Number of Year(s) Used		Condition
Lathe	CQ5250C		7	8		Acceptable
Boring Mill	N/A		1	5		Acceptable
Facing Machine	N/A		2	9		Acceptable
Drilling Machine	N/A		2	5		Acceptable
Milling Machine	N/A		1	13		Acceptable
Welding Machine	N/A		9	5		Acceptable
Testing Machinery
Machine Name	Brand & Model No.		Quantity	Number of Year(s) Used		Condition
X-Ray Machine	N/A		1	3		Acceptable
Quality Management System Certification
Certification	Certified By		Certificate No.	Business Scope		Validity Period
ISo9001:2008	CQC, CNAS		00110Q22699R0M/5100	Production of Sized Hydraulic Turbine		18/Mar./2010 -- 17/Mar./2013
