ZHLB-40C Series crayon  Filling Machine

This product is designed for crayon /liquid cosmetics. It is suitable for lipstick, pen type crayon, pigment, etc.

Stirring speed and temperature of each tank are controlled independently.

Adopted advanced automatic control technology (interface, PLC, network), parameter (time, temperature, switch and speed of conveyor) is set by human machine interface. Easy control and stable performance.

1.Framework made of hardened aluminum is easy to maintain.

2.It doesn’t need much time to train operator.

3.Individual temperature control by PLC for separate unit (tank, filling pump, filling house, filling nozzle and heating plate) to achieve precise temperature.

4.Automatic timer and counter.

5.Can perform with conveyor.

Techni cal Parameter

Power: AC 220V/1Ψ/50Hz

Power Consumption: 4.5kw

Working Air Pressure: 6Kg/cm²

Dimension: 850×750×1905mm

Filling Volume: 1-14ml/piece

Tank Capacity: 20L,double-layer tank heated by oil

Output: 8s/piece

Filling Precision: ±1%

Height of Working table: 620mm

Terms and Conditions:

Payment: 30%TT in advance, 70%TT before machine ship out;

Delivery time: around 50 days to leave our factory after advance payment and samples

Warranty: one year after shipment.

Packing: according to export standard

See following some photos :

Welcome to email us to know more advantages of our machine. We will send you videos and detailed photos together, which will surprise you !!
