Standard Model (Household Model)

Model

IT-380

IT-580

Q’ty of electrolysis plates

3 plates

5 plates

Electrolysis Plate Material

Platinum-titanium plate; manufactured by KOBE Steel, Japan

Voltage

AC110V / AC220V, 50/60HZ

Power Consumption

Max. 180W

Max. 230W

Inlet Water Pressure

0.9~5.0 kg/cm2

Electrolysis Method

Continuous electrolysis (built-in flow meter)

Water Flow Rate

Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kgf/cm2)
Water flow rate: 3 Liters/min. (based on inlet water pressure 2kgf/cm2)

Cleaning

10 second automatic cleansing after each alkaline water use
* manual cleansing option if Alkaline water consumption is below 30 liters

Electrolysis Levels

4 Alkaline levels, 1 Pure level and 1 Acidic level

Filter Material

Activated carbon fiber (ACF), manufactured in USA: NSF certified

Filter Service Life

6,000 liters(depends on source water quality)

Safety Protection Device

Current protection & Alarm only if drinking Acidic water

Dimension & Weight

Approx.: H 310mm x W 202mm x D 125mm
Weight: 4.1kg

pH Value

 (based on source water quality)

5~10

4.5~11

O.R.P Value

 (based on source water quality)

-650mv (Max.)

-850mv (Max.)
