V Series Agricultural Water Pump,Irrigation Water Pump
- NINGBO
- T/T L/C D/P D/A
You May Like
-
Manufacturer Best Price Submersible Pump Water Pump
-
Stainless Steel Submersible Sewage Water Pump With Cutter
-
Manufacturers Good Price Stainless Steel Electric Sewage Submersible Pump
-
Manufacturer Japan Stainless Steel Sewage Pump Submersible Water Pump Quality Choice
-
Stainless Steel Casting Sewage Submersible Pump
-
SCM SERIES CENTRIFUGAL ELECTRICAL CLEAN WATER PUMP (0.37KW 0.5HP)
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BAQIU | |
| Model Number | V180 | Theory | Other, submersible pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, electrical | Pressure | Low Pressure | |
| Application | Submersible |
export standard strong colour carton
Product Description
| Manufacturer V Series Agricultural Water Pump,Irrigation Water Pump |
| |
|
| Application |
Submersible sewage pump is composed of motor,water pump and sealing part.The water pump has impeller-volute structure,and it is under the single or three phase asynchronous motor.Mechanical seal is used as the motive seal between motor and water pump,and oil reasisting rubber O ring works as the static seal for the rabbet. Thus,the reliability of our machine is ensured.Meanwhile,the rotor shaft is made of stainless steel,so reliable machanical strength of the shaft is obtained,and the abrasion resistance and corrosion resistance of the shaft are both improved. Also,it facilitates the disassembly and maintenance of impeller |
| Operating conditions |
| Our pump is able to work normally and continually if the following requirements are met. |
| Medium temperature:Not over +40℃ |
| PH range of medium:4~10 |
| Max.density of medium:1.2x103kg/m³ |
| Voltage fluctuation range:10% of rated voltage |
| submersion depth:≤5meters |
| Motor |
| Single phase |
| Insulation class:B |
| Protection:IP68 |
| Work shop area | |||||||||
|
| BAQIU Company Introduction |
1)Taizhou BAQIU electrical and mechanical Co.,LTD which located in the home two of chinese water-Daxi, Wenling China.We are integratd manufactural factory. |
2)Our major productions are all kinds of water pumps.Based on excellent products and good reputation,they have won favorable views from customers both at home and aboard and passed some domestric. |
3)Our products are well sold in more than twenty province and cities in China,and exported to America,Europe, Australia and Southeast Asia etc. |
4)Quality always stands the first and honest is our concept.We provide reasonable price,punctuality and satisfying service.We sincerely welcome all the friends from the world to join in us and develop together. |
| Shipping & Payment |
| 1.FedEx/DHL/UPS/TNT for samples |
| 2.Batch goods delivered by sea |
| 3.Customers specifying freight forwarders or negotiable shipping methods |
| 4.Delivery Time:7-15 days for samples; 25-30 days for batch goods |
| 5.30%T/T or 100%LC,balance against the copy of B/L |
| More choices if you like ... | |||||||||
| | | |||||||
| | | |||||||
| How to order? |
| 1. Please tell us some detail information, such as the Capacity, Head, Medium, Voltage etc. |
| 2. We can recommend pumps for you according to your requirements as well. |
| 3. If you have the certificate requirements, please let me know. |
| 4. We will make quotation for you. After your confirmation, PI will send to you. |
| 5. We will arrange the order for you as soon as receiving your payment. |
| 6. After the goods finished, we will send the goods to you. |
| 7. Note: Customers can order all product samples we put or you can also have your own idea, as we are custom-made product supplier, so any change of goods are available. |
