hm Ss400 Standard H Beam Steel 200*100*5.5*8
US$ 600 - 900
/ Ton
10 Tons(Min. Order)
- Tianjin port
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Grade | Other, SS400 SS490 S235JR S355JR SS235JO SS275JR SS275JO | |
| Technique | Hot Rolled | Thickness | 200mm | |
| Application | struchral | Length | 12.0m | |
| Standard | JIS | Flange Width | 100mm | |
| Flange Thickness | 8mm | Web Width | 192mm | |
| Web Thickness | 5.5mm | Brand Name | jinxi | |
| Model Number | 200*100*5.5*8 jis h- beam |
Product Description
Specifications
for building ss400 standard hm H beam jis standardmechanical device.
MODEL: H100*100-H400*400
H200*100*5.5*
ss400 standard H beam jis standard steel of dixiong
hm h beam 200*100*5.5*8 steel
- Grade: Q235B, Q235, Q345B, SS400, A36…
- Standard: JIS/ ASTM/ GB/ BS/ ...
- Length: 5.8m, 6m, 12m, or as the customers’ requirements.
- Usage:
(1).used for the plant, high-rise building construction
(2).used for the bridge, shipment building
(3).used for lifting and transportation machinery, equipment manufacturing base building
(4).used for the support, foundation pile manufacturing
5. Payment terms: 30% tt in advance, the balance against the LC or the copy of BL.
Common Size
| H x B (mm) | T1 | T2 | JIS Weight (kg/m) | GB Weight (kg/m) |
| 100*100 | 6 | 8 | 16.9 | 17.2 |
| 125*125 | 6.5 | 9 | 23.6 | 23.8 |
| 150*75 | 5 | 7 | 14 | 14.3 |
| 148*100 | 6 | 9 | 20.7 | 21.4 |
| 150*150 | 7 | 10 | 31.1 | 31.9 |
| 175*90 | 5 | 8 | 18 | 18.2 |
| 175*175 | 7.5 | 11 | 40.4 | 40.4 |
| 198*99 | 4.5 | 7 | 17.8 | 18.5 |
| 200*100 | 5.5 | 8 | 20.9 | 21.7 |
| 194*150 | 6 | 9 | 29.9 | 31.2 |
| 200*200 | 8 | 12 | 49.9 | 50.5 |
| 248*124 | 5 | 8 | 25.1 | 25.8 |
| 250*125 | 6 | 9 | 29 | 29.7 |
| 244*175 | 7 | 11 | 43.6 | 44.1 |
| 250*250 | 9 | 14 | 71.8 | 72.4 |
| 298*149 | 5.5 | 8 | 32 | 32.6 |
| 298*201 | 9 | 14 | 65.4 | |
| 300*150 | 6.5 | 9 | 36.7 | 37.3 |
| 294*200 | 8 | 12 | 55.8 | 57.3 |
| 300*300 | 10 | 15 | 93 | 94.5 |
| 346*174 | 6 | 9 | 41.2 | 41.8 |
| 350*175 | 7 | 11 | 49.4 | 50 |
| 340*250 | 9 | 14 | 78.1 | 79.7 |
| 350*350 | 12 | 19 | 135 | 137 |
| 400*200 | 8 | 13 | 65.4 | 66 |
| 390*300 | 10 | 16 | 105 | 107 |
| 400*400 | 13 | 21 | 172 | 172 |
| 446*199 | 8 | 12 | 65.1 | 66.7 |
| 450*200 | 9 | 14 | 77.9 | 79.5 |
| 440*300 | 11 | 18 | 121 | 124 |
| 496*199 | 9 | 14 | 77.9 | 79.5 |
| 500*200 | 10 | 16 | 88.2 | 89.6 |
| 488*300 | 11 | 18 | 125 | 129 |
| 596*199 | 10 | 15 | 92.5 | 95.1 |
| 600*200 | 11 | 17 | 103.4 | 106 |
| 588*300 | 12 | 20 | 147 | 151 |
| 700*300 | 13 | 24 | 182 | 185 |
| 800*300 | 14 | 26 | 207 | 210 |
| 900*300 | 16 | 28 | 240.1 | 243 |
Specification Depth*flange width | Web thickness (mm) | Flange thickness (mm) | Weight (kg/m) |
| HE 240A 230*240 | 7.5 | 12 | 60.3 |
| HE 240B 240*240 | 10 | 17 | 83.2 |
| HE 260A 250*260 | 7.5 | 12.5 | 68.2 |
| HE 260B 260*260 | 10 | 17.5 | 93 |
| HE 280A 270*280 | 8 | 13 | 76.4 |
| HE 280B 280*280 | 10.5 | 18 | 103 |
| HE 300A 290*300 | 8.5 | 14 | 88.3 |
| HE 300B 300*300 | 11 | 19 | 117 |
| HE 320A 310*300 | 9 | 15.5 | 97.6 |
| HE 320B 320*300 | 11.5 | 20.5 | 127 |
IF YOU HAVE ANYTHING I CAN DO FOR YOU,PLS LET ME KNOW!
