JYSL amphibious dredger excavator , CE, EPA , Model: JYSL-350PD

Place of Origin	Shandong, China		Brand Name	JINYI
Model Number	JYSL-350PD		Condition	New
Moving Type	Crawler Excavator		Operating Weight	35 Ton
Bucket capacity	0.5 to 1.0 M3		Maximum Digging Height	9.89 -- 15.3 meter
Maximum Digging Depth	5.71 -- 10.6 meter		Machine Weight	35 Ton
Max Digging Radius	9.1 -- 15.6 meter		Rated Speed	7-9 Km/Hour
Certification	ISO9001 ,CE, EPA		After-sales Service Provided	Engineers available to service machinery overseas

Specifications

1.Engine: Cummins, ISUZU, DOOSAN
2.Arm: Standard arm or Long arm
3.Bucket: 0.5 to 1.0 M3
4.Pump water flow: 450-700 M3
5.OEM

We now have a stock DOOSAN DH215-9E Amphibious excavator (16M long arm) for sale at very competitive price. You can refer to the following web site to get more information.

 http://www.china.cn/product-detail/Long-arm-AMPHIBIOUS-EXCAVATOR-Swamp-Excavator_1911088319.html



*******************************************************************************************************************************************



We are factory that mainly produce 3Ton to 55Ton  amphibious dredger excavator and amphibious excavator by assembling different brands and model excavator upper parts, like PC200, HITACHI ZX210, DH215, EX120,SH120.... Also, if you have crawler excavator, we can only produce amphibious undercarriage (steel pontoon) for you. Sincerely wish could have chances to do businss with you and welcome you to visit our factory!



Application of JYSL series amphibious dredger excavator   :

1.Deepening of canal, river channel and river mouth

2.Swamp land clearing at mining area, plantation and forest

3.Building bund for flood prevention and land reclamation

4.Building bund wall for fish and shimp ponds and salt making industry

5.Sludge clearing of lakes, ponds and water reservoir

6.Digging trenches for oil and gas piping installation

7.Transporting and clearing landslide and flood hit area

8.Swamps and wetlands construction

9.Road construction through wetlands.







TECHNICAL PERFORMANCE AND SPECIFICATION OF JYSL-350PD



Engine	Engine model	Cummins 6BTA-5.9   ( Isuzu 6BG1TRP  )
	Fuel	Diesel
	Number of Cylinders	6
	Number of strokes	4
	Capacity	5.9L         ( 6.494L)
	Power	112KW     (120KW)
	Turbo charged	YES
	Water-cooled	YES
	Fuel tank	410L
Hydraulic System	Flow rate of pump	2 X 212 L / min
	Circuit of working devices	35000KP
	Circuit of walking	35000KP
	Circuit of turning	28000KP
	Swing speed	12 rpm
	Hydraulic pump model	KPM K3V112DT
	Control valve model	Parker AV-280
	Swing motor model	SUNJIN K250D
	Travel motor model	ETON JMV-147
Opeating Datas	Operating Weight	35000KG
	Maximum Tractive effort	205KN
	Arm size	Standard arm
	Lift of pump	7 -- 18 meter
	Water flow of pump	450 -- 700 M3 / Hour
	Bucket capacity	1.0M3
	Walking speed	7 KM / H (on land and swamp)                                                      9 KM / H (on deep water)
	Max.Working depth                                         (on water)	2.5 Meter (not assembling stabilizers)                                         8.0 Meter (by assembling stabilizers)





Model	Max. Digging Radius (M)	Max. Digging Depth (M)	Max. Digging Height (M)	Max.Dumping Height (M)
JYSL-350PD (standard arm )	9.1	5.71	9.89	7.09
JYSL-350-2PD (2M longer arm)	10.99	7.7	11.04	8.7
JYSL-350-3PD (16M long arm)	15.6	10.6	15.3	13.2







Dimensions ( JYSL-350PD )				mm
A	Track length			10000
B	Ground contact length of tracks			7600
C	Tail swing radius			2750
D	Overall length			11500
E	Overall height (to the top of arm)			3880
F	Ground clearance of counter weight			2025
H	Overall width			4940
I	Track gauge			3440
J	Track width			1500
K	Ground clearance			1140
L	Track height			1840
M	Overall height (to the top of cab)			3870
N	Width of the top part			2710





WORK PERFORMANCE

(JYSL-350PD with standard arm and 1.0M3 bucket)

(JYSL-350-3PD with 16M long arm and 0.5 M3 bucket )

( PRODUCTION WORKSHOP )
