Hot selling F2000 6X4 Shacman truck 2016

FOB Price

USD $100 - $38,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Hot selling F2000 6X4 Shacman truck 2016

Name			F2000 Dump Truck
Model			SX3254JM384
Drive type			6×4
Kerb mass (kg)			11200
Rated loading capacity(kg)			13670
Total mass(kg)			25000
Max. speed (km/h)			77
Min. turning diameter (m)			18
Approach/Departure(°)			16/66
Max. gradeability (%)			30
Appearance dimensions (mm) Length×Width ×Height			8275×2490×3450
Wheel base (mm)			3800+1350
Overhang(front/rear)			1525/1600
Track width (mm) (front/rear)			1939/1800
Engine			Steyr Engine, WD615.50,290HP E-II
Rated output power			213kw
Torque(N.m r. p. m)			1160/1100-1600
Displacement(L)			9.726
Fuel tank capacity (L)			380L iron tank
Tyre:			11R22.5 Tubeless
Clutch			φ430 diaphragm spring
Gearbox		Transmission	9JS135, 9F,1R
		Gear ratio	12.11 8.08 5.93 4.42 3.36 2.41 1.76 1.32 1 R12.66
Front axle			MAN 7.5T front axle
Drive axle			STR 13T×2 axle ratio 5.73
Steering			ZF technology(left-hand drive)
Brake	Service brake		With dual-circuit compressed air brake
	Park brake		Power spring brake acting on front & rear wheel
Cab			D’long F2000 lengthen-flat top cab, single bed with A/C, Manual window lifter
Body dimensions (mm)			5600×2300×1400mm bottom 8mm,side6mm
Lifting style			Middle lift
