XCMG XT670-140 14tm telescopic handler

FOB Price

USD $60,000 - $70,000 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	XCMG	Model Number	XT670-140
Type	Manual Pallet Truck	Power Souce	Diesel Engine
Rated Loading Capacity	10500KG	Max. Lifting Height	3m
Min. Lifting Height	1050mm	Fork Length	1220mm
Fork Width	165mm	Overall Dimensions	5560mm2300mm2565mm
Certification	ISO,CE	After-sales Service Provided	Engineers available to service machinery overseas

XCMG XT670-140 14tm telescopic handler

More Reasonable Design Optimized Sys
Hydrodynamic-mechanical transmission
4Wheel Drive Large Driving Digging Force
Best price

Technical specification:

model		XT670-140
Description	Unit	Specificatons
Overall dimensions(LWH)	mm	6290×2450×2725
Working weight	kg	10500
min.ground clearance	mm	450
Wheel base	mm	3250
Tread	mm	1977
Engine Model		/1104D-44T//Duzts TD226B-4IG2
Rated power	kw	74.5
Rated speed	r/min	2200
displacement	L	4.4
No.of cylinder		4
Max. speed	km/h	35
Fork length	mm	1200
Rear	mm	1190
Departure angle	°	36.4
Min.turning radius	mm	4238
Max. climbing capacity	°	26.5
foot brake/brake oil pressure	Mpa	wet type/4.4
hand brake		wet type/4.4
working specs		outriggers on ground	outriggers are not ground
Maximum lift capacity	Kg	3500	3500
Lift capacity to full height	Kg	2269	1350
Lift capacity at full reach	kg	453	225
Lift height	mm	13800	13500
Reach at maximum lift height	mm	1330	1955
Maximum forward reach	mm	8830	9457
