RAMC Series Japanese Yokogawa Flowmeter
US$ 100 - 1,000
/ Piece
1 Piece(Min. Order)
- ningbo or shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Japan | Brand Name | YOKOGAWA | |
| Model Number | RAMC series |
Product Description
Specifications
1.User-oriented Functionality2.Expansion of Product Lineup
3.Enhanced Performance
yokogawa flowmeter
we can provide all series yokogawa flowmeter
RAMC yokogawa metal flow meter
AXF yokogawa electromagnetic flowmeter
DY yokogawa svortex flow meter
Please tell me the MODEL you need
pls contact me:
SKYPE :
graph
2.Features
| - | Patended float blockage detection |
| - | Suitable for applications according to IEC 61508 and ISO 13849 |
| - | Intrinsically safe outputs or explosion proof housing available |
| - | Spacer for high/low temperature applications |
| - | Special material like Monel and Hastelloy on request |
| - | Easy to install and maintain |
3.Specifications
| For Pipe Sizes | DN 15 to DN 25 (1/4” – 1“) |
| Process Connections | Flange, threaded |
| Measuring Range | Water 20 °C: 2,5 l/h to 130 m³/h Air 20 °C 1 bar abs.: 75 l/h to 1400 m³/h |
| Wetted Parts Material | 1.4404 (AISI 316L), PTFE-lining Hastelloy, Monel and Titanium on request |
| Process Temperature | -200 °C to + 370 °C |
| Process Pressure | 100 bar, higher pressures on request |
| Ambient Temperature | -40 °C to 100 °C |
| Accuracy acc. VDE/VDI 3513-2(qG =50%) | 1,6 % |
| Ex-approvals | ATEX, FM(US,C), NEPSI |
| Signal Outputs | Analog 0-20mA / 4-20mA, pulse output |
| Communication | HART, Profibus PA |
| Power Supply | 24 V DC 2-wire, 24 V DC 3-wire, 115 V AC 4-wire, 230 V AC 4-wire |
| Degree of Protection | IP66/IP67 |
| Suitable for Applications acc. IEC 61508 and Machinery Directive ISO 13849 | Yes |
| Additional Features | Patented float blockage detection system Limit switches for low/high alarms Float damping for gas applications Flame proof/dust proof housing Heat tracing and temperature spacer |
