Truck-mounted Concrete Pump 48m,long Pump Truck Mouted

FOB Price

US$ 1 - 336,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Electric
Place of Origin	Henan, China	Brand Name	YUJIE
Model Number	48m truck mounted pump	Power(W)	275(1800r/min)
Weight	40000kg	Dimension(LWH)	1330025004000mm
Certification	ISO BV Certificate	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Truck-mounted concrete pump 48m,long pump truck mouted

name		unit	HDT5401THB-48/5
Working state Main Parameters	output in theory	m3/h	150
	index of the pump carry capacity	Mpa	586
	theoretic pumping pressure	Mpa	8.5
	bucket volume	L	700
	height of top surface of bucket	mm	1400
	model of distribution valve		S
	max. operation radius	m	43.7
	max. operation height	m	47.7
	max. operation depth	m	34.3
	open height of boom	mm	9065
	distance between front landing legs	mm	9780
	distance between rear landing legs	mm	9860
	distance between front & rear landing legs	mm	9470
	diameter of delivery pipe	mm	125
	length of hose pipe	m	3
	rotary range of boom		365°
	quantity of boom		5
	rotary angle of each boom	°	91/180/180/180/270
	wire line control distance	m	33
	remote control distance	m	200
Driving State Main Parameters	max. speed	km/h	85
	min. turn radius	mm	12100
	brake distance	m	10
	approach angle	°	16

chassis model		ZZ5437S4667C
wheel base between the first & the second axle	mm	1800
wheel base between the second & the third axle	mm	4600
wheel base between the third & the fourth axle	mm	1350
front tread	mm	2022
rear tread	mm	1830
max. engine output power	kw	275(1800r/min)
max. engine output torque	n.m	1500(1100r/min)
max, gradient ability	%	37
fuel consumption	L/100km	38
out dimension(L×W×H)	mm	13300×2500×4000
total weight	kg	40000
