Home > Products > Brick Making Machine > 2016 High Enquiry Automatic Brick Making Machine Clay Brick Machine QT6-15
2016 High Enquiry Automatic Brick Making Machine Clay Brick Machine QT6-15
- chinese main port
- T/T Credit Card
You May Like
-
Concrete Block Making Machine Price in India,used Concrete Block Making Machine for Sale, Block Making Machine Most Popular
-
China Hongfa Concrete Brick Making
-
Manual Block and Brick Making Machines
-
Automatic Brick Making Machine for Bangladesh
-
Cement Interlocking Brick Making Machine
-
Manual Brick Making Machine Design
Product Details
| Type | Hollow Block Making Machine | Brick Raw Material | Concrete | |
| Processing | Other, brick making machine | Method | Vacuum Extruder | |
| Automatic | Yes | Capacity | 57,600 Pieces/ 8 hours | |
| Place of Origin | Henan, China | Brand Name | YU JIE | |
| Model Number | QT6-15 |
Product Description
2016 High Enquiry Automatic Brick Making Machine clay brick machine QT6-15
1. PLC (computer automatic control): Hundreds program and process are ready to install, suitable for complex dynamic environment, and easy to handle.
2. Multi-source vibration system: For ensure the accuracy, the vibration frequency is adjustable.
3. Automatic diagnosis system: Unique system, Real-time monitoring to find out the fault, achieved remote- control by using telephone line.
Main Technical Parameters
1, QT6-15 hydraulic block making machine main technical parameters
Parameter Name | Parameter values | |
The largest machine dimensions | 6600×1990×3000(L×W×H)(mm) | |
Rated pressure of hydraulic system | 21Mpa | |
Main vibration form | All vibration molded desk | |
Vibration frequency | 50~70Hz | |
Vibration acceleration | 10-15g | |
To adapt to the high brick | 50-200mm | |
Pallet size | Wooden | 830×660×(40±1)(mm) |
Iron | 830×660×(8-10±1)(mm) | |
Bamboo | 830×660×(15-20)(mm) | |
Molding cycle | 15-18 seconds 20-23 seconds to be added fabrics |
|
When production | Standard block (240×115×53mm) | 57,600 Pieces/ 8 hours |
Feeder capacity | Effective storage volume of 0.45m3 hopper | |
| Effective volume of 0.15m3 car charging | |
Machine power | 36.8kw | |
Machine weight | 12T | |
