16ch Factory 5 Mp Hd Network Dvr Competitive Turkish Language Turkish Language 9206E

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	XKA
Model Number	9206E

Product Description

Specifications

Specifications
1.Digital Zoom:in both preview and playback
2.UPNP, with free DDNS
3.Dont support email alarm
4.Cloud network

Product specification :
1. Support HDMI/ VGA/ TV simultaneous video output
2. Support 16 / 8 / 4ch simultaneously video record & network transmission, 16ch support 2ch D1,14ch CIF playback, 8ch support 2ch D1+6ch CIF playback, 4ch support 4ch full D1 playback, and 16 / 8 / 4ch CIF/QCIF sub-code stream
3. H.264 dual-stream video compression
4. Zoom function in both preview and playback
5. Support P2P function and 3G
6. Support UPNP, Build-in free DDNS
7. System supporting a variety of languages menu.
8. Support Multi-code stream technology, and remote surveillance (Iphone, android, symbian, windows and blackberry)
9. Adopted Graphic user operation interface, support USB mouse,wireless mouse,panel and remote operation. Support 2 SATA HDDs, support moveable hard-disk back-up.
10. Support varied PTZ control protocol , and embedded web visiting ,support HTTP, SMTP, FTP, DDNS, DHCP, PPPOE, and NAT traversing .
11. Support SMTP,SSL,email alarm, and JPEG capture and email
Parameters :
Model :	9206E	9208E	9204E
Operation system	Embedded Linux operation system
System resources	Support 16 / 8 / 4ch simultaneously video record & network transmission, 16ch support 2ch D1,14ch CIF playback, 8ch support 2ch D1+6ch CIF playback, 4ch support 4ch full D1 playback, and 16 / 8 / 4ch CIF/QCIF sub-code stream
Operation interface	Graphic Operation interface, Support USB mouse, IR remote, Front panel operation
Video standard	PAL,NTSC
Video compression	H.264
Audio compression	G.711
Record mode	Manual ,timing , alarm , motion detection record
Video search	Time/date ,event , channel , log
Backup mode	Network backup ,USB backup,inner SATA burner
Video input	16ch BNC	8ch BNC	4ch BNC
Video output	1ch BNC,1ch VGA,1ch HDMI
Audio input	4ch RCA	4ch RCA	4ch RCA
Audio output	1ch RCA
intercom	support
Monitoring quality	PAL: 720576 (D1) ; NTSC:720480 (D1)
Playback quality	P:352288(CIF) / 720576(D1) N:352240(CIF) / 720140(D1)		P:720576(D1); N:720480(D1)
Image control	6 degree adjustable
Motion detection	Each channel can set up single detection zones, and multistage sensitivity
Image split	1/4/9/16	1/4/9	1/4
record rate	PAL: 1~25fps (adjustable), NTSC:1~30fps (adjustable)
record storage	Local HDD and network
Local playback	1~16ch	1~8ch	1~4ch
Alarm input	4ch input (optional)
Alarm output	1ch output
PTZ control	RS485
HDD Interface	2 SATA
Network	1 RJ45 10M/100M adjust-automatically Ethernet interface
USB interface	2 USB2.0 high-speed interface
Power supply	DC 12V
Ax dimension	1.5U 36025060 mm
