pcb prototype machine for sale ZK-3030
- Qingdao
- Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | ZHUOKE | Model Number | ZK-3030 | |
| Rated Power | 900W | Engraving Speed | 0-3000mm/min | |
| Main Axle Rotational Speed | 0-24000rpm/min | Feeding Height | 40mm | |
| Milling Cutter Diameter | 3.175,4,6mm | Application | PCB engraving/cutting/drilling/milling | |
| Dimensions | 820X780X800mm | Weight | 109kg | |
| Certification | CE | Warranty | One year under normal use |
Product Description
pcb prototype machine for sale ZK-3030
Application:
1.This machine is designed for pcb working such as :pcb drilling,milling,engraving,cutting.
2.This machine can also used for many area,such as:
advertising engraving and cutting,wood working,mini craft engraving and cutting.
3.with water channel,this machine can also used for metal or stone engraving and cutting
Packing:
body dimensions: 620*630*550mm
pack dimensions: 850*800*800mm
Net weight: 70kg (with bracket)
Gross weight: 96 kg
free fumigation wooden box
Machine parameter
Model | ZK-3030A | Model | ZK-3030A |
XY-axis working size | 300*300mm | Repeat accuracy | 0.025mm |
Z-axis working size | 40mm | Drilling holes | 40-100/min |
Driving way | Ball screw | Command | G code,u00,mmg,plt,HPGL |
Working panel | Single/double-side board | Compatible software | PowerPCB, Protel99 |
Least step distance | 0.003125mm | Software running environment | WindowsXP |
Max. speed | 5000mm/min | Spindle power | 800W variable speed, water-cooled motor |
Working speed | 0-3000mm/min | Spindle speed | 0-24000rpm/min |
Working accuracy | 6-8mil | Driving mode | Stepper motor |
Least line diameter and least line spacing : | 6-8mil | Control system | NCstudio/DSP |
Drilling depth | 0.02-3mm | Power source | AC220V 50Hz orAC110V 60HZ |
Drilling diameter | 0.4-3.175mm | Relative humidity | 30%-75% |
Product feature:
1.Guide Rail: Adopt Taiwan HIWIN import straight party rail.Good stability,high accuracy,lower wastage. The X.Y.Z Axis use import high precision and lower wastage extended nut automatic disappear gap ball-screw.
2.Portal Frame: Use aviation industry aluminum, long service time, resistant to wear and low noise.
3.spindle : Water-cooling spindle, resistant to wear and low noise and can cooling the machine timely and effective .
4.High accuracy , It could engrave 2mm-3mm little letter.
5.The control box adopts advanced CNC system, making it high stability. The high speed subdivided engraver motor is installed to ensure low noise , nonpolar speed change make the spindle revolving speed reach 24000r/min.
Machine details
T-slot table coverd arcrylic
ballscrew,crlindrical guideway,800Wspindle
PCB tools and 57-311 step motor
machine Z axis and control box
Spare parts(for free):
Clamp-----------------------------4
Spanner---------------------------2
Brush------------------------------1
Software in CD--------------------1
Controlling Card (PCI card)-----1
Water Pump-----------------------1
Engraving And Cutting Tools---24
Data Wire---------------------------1
Power Line------------------------- 1
Key point:
Please kindly tell us your needed working area.
We have 300*300mm, 400*400mm, 600*600mm or make it for you.
Pls kindly tell us the material you will working on and the destination so that we can give you our exact price.
Sample pictures
If you are interested in our product, please contact me when free, we will never let you down!
Contact person: Yvonne Zhu
