Hot Sale Whole White 4 Axis Advertising CNC Engraving Machine ZK-6090 With Ball Screw Transmission Mach3 Control System
- Qingdao/Guangzhou/Shanghai or as you need
- D/P D/A
You May Like
-
Small Size 4 Axis CNC Engraving Machine ZK-6090 600*900MM For Wood Acrylic With Stepper Motor&3.2KW Water Cooling Spindle
-
New Design Small 6090 Wood Acrylic CNC Router Machine With 4 Axis&Mach3 Control System
-
High Quality 4Axis CNC Router Machine ZK-6090 For Acrylic Wood Aluminum With Ball Screw Transmission&3.2KW Water Cooling Spindle
-
China Color Optional 4 Axis Advertising CNC Router Machine ZK-6090 For Wood Acryllic With Mach3 Controller
-
Discount Price 3D Wood Carving Machine ZK-6090 600*900MM For Wood Acrylic MDF With 4 Axis Of DSP Offline Control System
-
China Brilliant 4 Axis CNC Engraver For Wood Acrylic PVC ZK-6090 600*900MM With Water Cooling Spindle Of DSP Offline Controller
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | Zhuoke | |
| Model Number | ZK-6090 | Voltage | 220V | |
| Power(W) | 3.2KW | Dimension(L*W*H) | 150*120*163cm | |
| Weight | 350kg | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Hot Sale Whole White 4 Axis Advertising CNC Engraving Machine ZK-6090 With Ball Screw Transmission Mach3 Control System
Technical Data:
Items | Description | Optional |
Effective working area | 600(X)mm*900(Y)mm120(Z)mm |
|
Max. thickness of the materials | ≤200mm(the distance between Z-axis and the bottom of the working station) |
|
Materials | Cast iron machine bed, cast aluminum gantry |
|
Working table | Aircraft aluminum T slot |
|
Guide rail | Linear round guide rail
| Or linear square guide rail(Taiwan,HIWIN) |
Transmission | Ball screw for X Y Z-axis |
|
Driving mode | Stepper motor | Servo motor |
Spindle motor | 3.2kw water cooling | Or 2.2/1.5kw/air cooling |
Spindle speed | 0-24000rpm/min |
|
Empty traveling speed | 0-8000mm/min |
|
Engraving speed | 0-6000mm/min |
|
Resetting accuracy | 0.05mm |
|
Control system | Mach3 | PCI NcStudio or DSP Offline |
Carving Instructions | G code *Uoo *mmg *plt HPGL |
|
Packing size | 1520*1200*1600mm |
|
Gross weight | 350kg |
|
Applicable Industries:
Good at in processing all kinds of small workpiece, widely uesd in advertising signs, badges, logo, mould construction equipment, mould products, industrial mold, etc.
Applicable Materials:
Suitable for all kinds od metal, such as copper, aluminum, iron, stell, stainless steel, alloy, also the acrylic, wood, MDF, double color board, stone, jade, ect.
Machine features:
1. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
2. Adopt 3.2kw water cooling spindle.
3. The machine adopts working table movement, it can process any kinds of materials freely.
4. Three axis adopt imported ball screw and cirle orbit, stable working, high precision and long life time.
5. X axis is dustproof.It makes sure the steady working performance of the machine for long-term using.
6. Well compatibility:CAD/CAM designing software, e.g.Type3/Artcam/Castmate/Wentai etc.
7. Has the function of forecasting process time.
8. High precision, the curving and linear speeds are consistent.Adopting execellent parts makes the fault rate to be the lowest one.
