WF-LA001 high quality steel dust suppression system for coal yard

WF-LA001 high quality steel dust suppression system for coal yard

high quality steel dust suppression system for coal yard

Steel dust suppression system is an advanced technology to solve the dust pollution in the open yard of bulk materials. Steel dust suppression system is widely used in port, power plants, coal mines, cement plants, and other business fields which have coal yard or raw material yard. With using of the steel dust suppression system, the wind can be effectively controlled, thereby suppress the arousing of dust. Dust suppression rate can reach up to 80% by means of our steel dust suppression system for coal yard alone. And, if combined with a water spray system, the dust suppression rate can be over 95%, but the water consumption amount can be significantly reduced.

Specifications of our steel dust suppression system
Our steel dust suppression system for coal yard consists of three parts: the foundation, steel structure and the steel windbreak panel. The steel structure is customer designed according to factors such as the coal pile height, wind load, desired earthquake resistance, etc. All structural posts of our dust suppression system for coal yard is completed in factory. The steel windbreak panels are fastened on the steel structure on site by stainless bolts and nuts.

Foundation of our dust suppression system for coal yard

Steel structure of our dust suppression system for coal yard

Steel windbreak panels of our dust suppression system for coal yard

Working principle of our dust suppression system for coal yard

Our dust suppression system can control and improve the airflow field of the coal yard. When a strong wind meets the wall, only part of it can pass through, so the mechanical energy weakens and converts to low speed airflow. A new airflow field of the yard area is formed, which with low wind speed gradient, low-speed rotation, weak turbulence intensity and thus can reduce the dust diffusion in the lower place of the coal yard.

Benefits of our dust suppression system for coal yard

1. Economical benefits
Reducing the loss of raw materials;

Improving the space utilization of the coal yard;

Low maintenance cost;

Long life span.

2. Social benefits
Improving the environment quality nearby the coal yard;

Improving the working environment of the workers in the coal yard;

Beautifying of local region because of optional colors of the appearance.

Information needed for design of our steel dust suppression system

For our steel dust suppression system design, the customer needs to provide the following details:

1. Natural conditions
Including temperature, precipitation conditions, fog conditions, wind conditions, geological conditions, desired earthquake resistant levels, etc.

2. Coal yard situation
Including the surrounding environment, yard size, stockpile geometry.

3. Customers' requirement
Customer's demand of dust suppression rate, anti corrosion, flame retardancy, acid and alkali resistance, service life, etc.

With above information, we can supply you the following designs for dust suppression system:
General layout design
Height design
Wall panel design
Steel structure and foundation design

Our company

Green (Tianjin) Technology Development Company, Ltd. is a Chinese manufacturer specializes in the production and installation of steel windbreak and dust suppression system. We strictly follow the modern enterprise management mechanism and have passed the authorization and audit of ISO9001: 2008, ISO14001: 2004 and ISO18001: 2001 quality management systems. Green Technology has established close cooperation with universities, research and design institutes to guarantee superior quality and excellent performance of the steel windbreak and dust suppression wall system. Our company owns the qualification of Environmental Engineering Contractor ( Grade Ⅲ ), Steel Structure Engineering Contractor ( Grade Ⅲ ) and possesses more than 20 patents.
