WF-AF009 factory sale wind barrier design for coal pile with steel posts

WF-AF009 factory sale wind barrier design for coal pile with steel posts

How wind barrier design for coal pile work

Strong wind with large scale and high strength vortex in front of the wind barrier is combed into small scale and weak strength vortex. Only part of wind can go through the wind barrier. Its mechanical energy is decayed and turns into low speed airflow.

                            Schematic diagram of steel wind barrier

After the strong wind going through the wind barrier, the lowered speed, weakened turbulence intensity wind flows across the storage yard. It becomes a wind with low gradient speed, low curl, weak vorticity and turbulence intensity, which greatly reduced the dust quantity in lower part of the storage yard. When the strong wind comes to wind barrier, airflow interference appears and the coming wind speed is reduced. Thus, the kinetic energy of coming wind is greatly reduced. The shearing stress and pressure on surface of the storage pile is reduced, thereby achieving the effect of reducing the fugitive dust pollution.

                                    Schematic diagram of steel wind barrier for coal pile

What components included in wind barrier design for coal pile

The wind barrier design for coal pile is formed by three parts: foundation, steel structure and steel windbreak panel. The steel structure is designed mainly in accordance with height of storage pile, wind load, earthquake and other factors. Each structure post is completed in factory. The steel wind barrier panels are fastened on the structure by stainless stell made bolts and nuts.

Specifications of steel wind barrier design for coal pile

Pictures of steel wind barrier design for coal pile

Processing flow of steel wind barrier design for coal pile corrosion prevention coating

Benefits of steel wind barrier design for coal pile

1,Economic benefit of wind barrier design

Reducing loss of stock in the stock yard

Reduce the damage to facilities due to strong wind

Increase the operation rate of storage yard

2,Social (environment) benefit of wind barrier design

Improving living environment for neighboring inhabitants

Improving working environment for field men

Reducing dust pollution in neighboring environment and water area

Company information

Green (Tianjin) Technology Development Co., Ltd. locates in Baodi Jiuyuan Industrial Park with registered capital of 10 million U.S. dollar and total investment 25 million U.S. dollar. Green Technology is the only research and manufacturing enterprise in Tianjin who specializes in the control of wind, sand, snow and dust. The designed daily output of steel windbreak dust fence panel is 12,000M². Green Technology is supplying a scientific and effective solution for the ports, terminals, power plants, cement factories, coal mines, roads, railway, agriculture and other fields that face the  problem caused by wind, sand, snow and dust.

Green Technology strictly follows the modern enterprise management mechanism and has passed the authorization and the audit of ISO9001: 2008, ISO14001: 2004, ISO: 18001:2001 system.  The company owns the qualification of Environmental Engineering Contractor (Grade III) and Steel Structure Engineering Contractor (Grade III). "WALMAX" is the registered trademark. Green Technology possesses more than 20 patents concerning wind, sand, snow and dust control. The company is equipped with advanced automatic spraying production line, salt fog test machine and the static and dynamic load laboratory. Green Technology is striving for bringing blue sky to the earth and creating beautiful life for human beings through WALMAX brand wind, sand, snow and steel dust fence control systems.
