CH-LA079 40ft shipping container house for living

40ft shipping container house

Model

External Size (L*W*H)

Thickness of

insulation(mm)

Internal Size (L*W*H)

Weight

20FT-50

12116*2438*2896

50

11950*2260*2600

3500-4000KG

20FT-75

12116*2438*2896

75

11900*2210*2550

20FT-100

12116*2438*2896

100

11850*2160*2500

Other standard sizes of our modular shipping container house

Item

10ft shipping container house

20ft shipping container house

Length

3028mm

6058mm

Width

2438mm

2438mm

Height

2896mm

2896mm

Nonstandard size's shipping container house can also be designed

Framework

Top beam frame

Q235, 4mm or 5mm galvanized channel steel

Base beam frame

Column

Purlin

Q235, 4mm or 3mm steel pipe

Wall

External wall

1.6mm or 1.8mm color steel sheet

Insulation

50/75/100mm PU/EPS/Rock wool/Glass wool

Glass wall

Transparent glass

Decorative board

PVC

Roof

Steel roof

1.6mm or 1.8mm color steel sheet

Sandwich panel roof

50/75/100mm PU/EPS/Glass wool sandwich panel

Ceiling

PVC panel or Gypsum board

Floor

Decorative board

PVC, bamboo plywood or floor leather

Bearing plate

1.6mm or 1.8mm color steel sheet

Insulation

50/75/100mm PU/EPS/Glass wool

Door

Front Door

Plastics-steel/Synthetic wood, 2000 x 750 mm

Room Door

PVC/Synthetic wood, 2000 x 600 mm

 Window

Material

Plastics-steel/PVC, single glass

Size

1500 x 1000 mm, customized

Optional systems

Electric system

Customized design

Drainage system

16-20mm diameter PVC or steel pipe

Exhaust fan or air exchange hole

steel or PVC, 250mm*250mm

1. Attractive Looking

The size, color and decoration of the 40ft shipping container house can be customer designed.

2. Safe and Comfortable

The sandwich panels of the 40ft shipping container house have good heat and sound insulation and good fire resistance. And owing to the drainage system, this 40ft shipping container house is completely waterproof.

Thermal conductivity

<0.036W/(m×K)

Temperature range

-40 to 50 ℃

Fire resistance

B1 Grade

Noise reduction

40db

3. Convinient Transportation

The 40ft shipping container house can be easily transported by using a hoist and a truck.

4. High Quality

High quality light steel is adopted by our 40ft shipping container house. Although with a light weight, the shipping container house is strong enough to face impacts.

Roof load

0.75KN/m2

Floor load

2.0KN/m2

Wind resistance

12-Level

Seismic resistance

10-Magnitude

5. Long Lifespan

Steel materials of the 40ft shipping container house have been surface treated by galvanizing and multi-layer coating. Our 40ft shipping container house can serve at least 25 years.
