150bar Pressure Plunger Reciporocating Pump
US$ 7,600 - 14,300
/ Set
1 Set(Min. Order)
- Shanghai
- T/T D/P D/A
You May Like
-
WLQ55/50 High Pressure Water Jet
-
High Pressure Industrial Cleaner
-
WLQ 70/70,80/50 SERIES HIGH PRESSURE MACHINES Oil-filled Anti Vibration-type Pressure Gauge
-
Filtrating Equipment for Make Water Clean for High Pressure Washer for Sale
-
High Pressure Hose for High Pressure Cleaner
-
High Pressure Water Hose
Product Details
| Brand Name | LingFeng | |||
| Model Number | WLQ300/15 | Theory | Other, Reciprocating triplex plunger pump | |
| Structure | Other, Triplex Plunger Pump | Usage | Water | |
| Power | Hydraulic | Standard or Nonstandard | Standard | |
| Fuel | Other, Motor /Diesel | Pressure | High Pressure | |
| Application | Other, Power Source |
Product Description
Features of Triplex Pumps:
1:It's the generating equipment of high pressure
injection.
2:Different from the traditional single-stage pump, it is horizontal triplex plunger reciprocating pump
3:Out pressure is 10-100Mpa
4: Application:high pressure cleaners ,which apply in oil field,suagr cane factory,electricity station,sewer pipe cleaning , etc .
NOTE:
pressure & flow is adjustable according to user's request!
| Technical Parameters | |||||||||||
| Dimension(L*W*H):0.87*0.85*0.44m | Dimension(L*W*H):0.925*0.86*0.49m | Dimension(L*W*H):1.02*0.99*0.53m | |||||||||
| Weight:468kg | Weight:546kg | Weight:906kg | |||||||||
| Rotating Speed:1480r/min | Rotating Speed:1480r/min | Rotating Speed:1480r/min | |||||||||
| Model No | Flow | Pressure | Power | Model No | Flow | Pressure | Power | Model No | Flow | Pressure | Power |
| (WLQB) | (L/Min) | (Mpa) | (Kw) | (WLQB) | (L/Min) | (Mpa) | (Kw) | (WLQB) | (L/Min) | (Mpa) | (Kw) |
| 80/35 | 80 | 35 | 55 | 60/70 | 60 | 70 | 75 | 55/100 | 55 | 100 | 110 |
| 63/50 | 63 | 50 | 55 | 135/30 | 135 | 30 | 75 | 173/30 | 175 | 30 | 110 |
| 70/50 | 70 | 50 | 75 | 45/100 | 45 | 100 | 90 | 90/75 | 90 | 75 | 132 |
| 55/50 | 55 | 50 | 55 | 70/70 | 70 | 70 | 90 | 80/100 | 80 | 100 | 160 |
| 135/20 | 135 | 20 | 55 | 90/50 | 90 | 50 | 90 | 175/45 | 175 | 45 | 160 |
| 250/11 | 250 | 11 | 55 | 300/15 | 300 | 15 | 90 | 260/30 | 260 | 30 | 160 |
...
