300M Wireless HDMI/SDI Transmitter

Specifications

Overview

A camera mounted wireless transmitter for uncompressed HD & SD video and audio signals from full size ENG / EFP broadcast

camera to field monitor or outside or studio production facility.

This system has no noticeable delay in video and audio transmission signals, allowing it to be used in live to air programming.
The system has an operational range of 300m with an Omni antenna system fitted.
The director, producer and production crew can now see exactly what the camera is shooting in real-time.

Features

 HDMI 1.3 spec

 HDMI and 3G SDI input and output

 Resolutions up to 1080P 60Hz,no delay and no compression

 Support audio formats include Dolby True HD, DTS-master, etc.

 AES-128 encryption with air interface HD video data stream

 Support point to point, and point to multi point network topology

 Each RX paired to the unique TX in factory,

 5GHz ISM frequency band,maximum 10 frequency channel selected manually, coexist with WIFI.

 Operational range up to 300meters

 Signal indicators for wireless net status, Video status and receiver RSSI

 Wide range power voltage input, adapt most kinds of camera battery

 Optional Sony F970 battery buckle, convenient for field battery install and replacement

 Any input and output ports with ±8 kV ESD protection level (HBM, contact discharge)

 Industrial metal case, stable and reliable
