150kw Shangchai marine generator power powered by Shangchai 6135JZLCaf engine with CCS

FOB Price

USD $3,000 - $6,500 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Chenlong
Model Number	CCFJ150W	Output Type	AC Three Phase
Speed	1500RMP	Frequency	50HZ
Rated Power	150kw/187.5kva	Rated Voltage	400/230V
Rated Current	270A

Product Description

150kw Shangchai marine generator power powered by Shangchai 6135JZLCaf engine with CCS
Gensets model	CCFJ150W
Prime power	150kw/187.5KVA
Rated Voltage(V)	400/230
Rated frequency(HZ)	50
Rated Speed(RPM)	1500
Power Factor	0.8(lagging)
Dimensions(mm) (L×W×H)	2350x1150x1300
Genset Weight(kg)	2400
Class	CCS,BV,IMO Tier2
2. Specification of diesel engine
Engine model	Shangchai 6135JZLCaf
Output power	180KW
Number of Cylinders	6
Cylinder arrangement	in line
Cycle	Four stroke
Aspiration	Direction injection
Bore×Stroke (mm×mm)	135x 150
Displacement (Liter)	8
Compression Ratio	16.4:1
Speed Governor	Mechanical
Cooling System	Forced Water Cooling Cycle
Total lubrication system capacity (L)	25
Fuel Consumption at 100% Load (g/kw.h)	210
Starting Method	DC24V electrical starting
3. Specification of alternator
Alternator brand	SUNVIM
Alternator model	SVH274G
Rated power	150KW
Number of Phase	3
Connecting Type	3 Phase and 4 Wires
Number of Bearing	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class	H
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%~+20%

FAQ

Q1: How is your Warranty?
Warranty: All FLYING DRAGON MERCHANDISE are warranted in accordance with our warranty terms

for a period of 12 months from date of dispatch or 1,000 running hours from date of commissioning whichever comes earlier.

Q2: Any advantages about your company?
-- Fast delivery time
-- Good design and high quality
-- Good service after sale
-- High quality with good price help you get more benefit and beat your competitors

Q3: Can you supply OEM service?
Yes, we can offer OEM service

Q4: How about the service after sale?
We have agents spread all over the world, our service network spanning more than 50 countries so we can ensure fast and good service for our clients. We are recruiting agents, welcome you to be our friend and get a win-win cooperation .
