9kw air-cooled electric diesel generator, home use mini power plant for sale

                                      9kw air-cooled electric diesel generator, home use mini power plant for sale

Technical Parameters for 9kw air-cooled electric diesel generator, home use mini power plant for sale:

1. Generator Model: CL-9AG;

2. Output power：9KW/11.25KVA,

3. Rated Voltage: 400/230V;

4. Dimension （L X W X H）mm：870*630*700;

5. Weight：195Kg;

6. Power factor: Cos=0.8(lagging);

7. Output socket: Single-phase socket or three-phase socket;

8. Bore*stroke(mm*mm):86×72;

9. Compressed ratio: 20:01.

10. Cooling way: Air cooled;

11. Starting way: DC 12V electric;

12. Engine structure: 2-cylinder, four cycle, DI;

13. Engine Model: R2V840;

14. Lubricating capacity(L):1.7;

15. Rotating Speed: 3000/3600RPM;

16. Displacement: 836L;

17. Oil used: SAE10W30(CD grade above);

18. Fuel used: 0#(summer) -10#(winter) -35#(cold winter) light diesel.

19. Fuel consumption under full loading (L/H):3.5;

20. Fuel tank capacity(L): 25;

21. Continuous running time (H): 7.1;

22. The regulation of rotating speed: Electronic speed.

23. Start motor capacity(V-KW): 12V 8.3kW;

24. Battery capacity(V-AH): 12V 45AH;

25. Alternator configuration: Brush, single bear 2 poles self-excited constant voltange with AVR;

26. Insulation Class: H degree.

Panel type for 9kw air-cooled electric diesel generator, home use mini power plant for sale

Intelligent

Packing Details of 9kw air-cooled electric diesel generator, home use mini power plant for sale:
Packed with carton;

Delivery Details for 9kw air-cooled electric diesel generator, home use mini power plant for sale:
7 working days after receiving the deposit.
