SBW Three Phase Compensated Voltage Stabilizer used in school
- NINGBO SHANGHAI
- T/T
You May Like
-
SBW power ac automatic voltage stabilizer used in hospital
-
SBW servo motor voltage stabilizer use for industry made in china
-
SBW Three phase Voltage stabilizer used in railway
-
SBW-200KVA Full Automatic ac Voltage Regulator/Stabilizer made in wenzhou
-
SBW series high power stabilizer,SBW-F1200KVA made in china
-
SBW Three Phase Automatic Voltage Stabilizer for railway
Product Details
| Place of Origin | Zhejiang, China | Brand Name | AKSDQ | |
| Model Number | SBW/DBW | Usage | Other, SBW/DBW | |
| Phase | Three Phase | Current Type | AC |
Product Description
SBW three phase voltage stabilizer:
1.Model:SBW
2.Function:adjust voltage
3.Standard:IEC/EN 61558
4.Input voltage:304~456V
5.Output voltage:380V±(1-5%)settable
6.Rated capacity:30KVA~1000KVA
7.Rated frequency:50/60Hz
8.Features:high efficiency,large capacity
9.Certificate:ISO9001:2008, FCC, CE
General
SBW Thress phase power voltage stabilizer in accordance with international similar products, combined with China's national conditions based on the development and production of a new generation of energy-saving electric power voltage regulator.
With a large capacity, high efficiency, regulators wide range, high precision, strong protection, no waveform distortion, reliable operation, easy maintenance and so on
It is widely used in post and telecommunications, industrial and mining enterprises, schools, railways, hospitals, printing, scientific research and all other required voltages normal occasions, and some auxiliary power supply equipment and critical equipment
Specifications
| DBW 50~350kva | SBW 30~1000kva | |||
| Input voltage range | 160~250V | 304~456V | ||
| Output voltage | 220V±(1~5)% settable | 380V±(1~5)% settable | ||
| Regulation accuracy | <±(1~5)% settable | |||
| Insulation resistance | ≥2MΩ | |||
| Withstand voltage | 2000V/1min no disruption or flashes phenomenon | |||
| Frequency | 50 / 60 Hz | |||
| Response time | <0.5s | |||
| Efficiency | ≥98% | |||
| Waveform aberration | <1% | |||
| Ambient temp & relative humidity | -5°C ~+40°C less than 90% | |||
